• Model NO.：SD13
• Color：Yellow
• Operating Weight：13.7 Ton
• Transport Package：Standard Package for Shipment
• Specification：ISO
• Trademark：Shantui
• Origin：Jiangsu, China
• HS Code：84291190
• Production Capacity：60 PCS,Month

ITEMUNITSD13L×W×H (Ripper not included)mm4492×3185×2950Operating weight (Ripper not included)t13.7Engine-Shangchai SC8D143G2B1Rated powerkW/rpm95.5/1900Gradeability°30Blade type-Straight tilt blade Angle bladeBlade widthmmStraight tilt blade 3185×1090 Angle blade 3475×915Dozing capacitym3Straight tilt blade 3.7 Angle blade 3.4Ma× drop below ground of blademm590Lift height of blademm930Ripper type-Three-shank ripperRipping depth of rippermm467Lifting height of rippermm559Number of carriers (each side)-2Number of track rollers (each side)-6Number of track shoes (each side)-38Width of track shoemm460Track gaugemm1880Ground length and ground pressuremm/MPa2365-0.063Pitchmm190Forward speedkm/h0-3.20-5.90-9.8Reverse speedkm/h0-3.90-7.1

Features

The extended track ensures low ground pressure, high reliability and strong traction, contributing to precise operation;

The power shift transmission not only ensures smooth power shift, but also reaches target speeds and carries out directional transfers with a single control lever;

The wet steering clutch and brake can extend service life. They work interactively, ensuring quick and flexible steering operations;

The single control lever can control all blade actions;

The drift sealing in the drive wheel, track roller and carrier roller can prevent dust from entering the track system, as well as lubricant leakage, thereby ensuring a long service life;

The hexahedron cab features wide visibility, and the insulation materials in the cab can reduce noise and vibrations;

The spin type fuel filter and dust separator, the air filters and the other filtration devices can prolong work time and reduce service time;

The comfortable cab seat can adjust upward and downward, forward and backward, meeting any positional needs the operator may have;

Side engine operation and the combination of a drive/brake operation system and foot brake makes overall operation of the bulldozer more rapid and convenient.
