| Manufacturer | XGMA |
| Model | XG962H |
| Overall length(mm) | 8820 |
| Overall height(mm) | 3465 |
| Overall width(mm) | 2835 |
| Wheel base(mm) | 2880 |
| Ground clearance(mm) | 435 |
| Tread(mm) | 2240 |
| Bucket Width (mm) | 3145 |
| Turn radius(mm) | 6350 |
| Min.Turn radius outside of bucket (mm) | 7470 |
| | 4225 |
| Max. Dumping Height(mm) | 3340 |
| Dumping Reach(mm) | 1330 |
| Digging depth(mm) | 60 |
| | |
| | | |
| Engine model | SC11CB240.1G2B1 |
| Rated power (kw) | 175 |
| Fuel comsumption per hour(g/kw.h ) | ≤225 |
| Rated speed (r/min) | 2200 |
| Max torque(N.m) | ≥1000 |
| Operating Weight (Tonnes) | 20.4 |
| Rated Load(Tonnes) | 6 |
| Bucket capacity (m3) | 2.6-5.5 |
| Lifting time/Lifting, dumping and lowering(s) | 6.5/10.5 |
| Max Breakout force(KN) | 175 |
| Max. turning angle(°) | ±35° |
| Fuel tank(L) | 340 |
| Hydraulic tank(L) | 305 |
| Working pressure of steering hydraulic system(MPa) | 16 |
| Working pressure of load hydraulic system(MPa) | 20 |
| Travel speeds(km/h) | FORWARD 1ST | 0~6.7 |
| FORWARD 2ND | 0~11.8 |
| FORWARD 3RD | 0-23.5 |
| FORWARD 4TH | 0-37.6 |
| REVERSE 1ST | 0-6.7 |
| REVERSE 2ND | 0-10.6 |
| REVERSE 3RD | 0-23.5 |
| Gear Box | ZF |
| Axle | XG |
| Implement pump | 209 |
| Distibuting valve | D32 |
| Steering Hydraulic system | BZZ6-1000 |
| Steering pump | 143 |
| Tyre size | 23.5-25-20PR |
| Air Conditioning/Anti-mist when idleing | √ |
| Heating | √ |
| Radio/Cassette | √ |
| Bucket and arm raiseing (limit height) Device | √ |
| Hydraulic Operation system | √ |
| Electricial Monitor and alarm system | √ |
| Seat Buckle | √ |
| Head lamp | √ |
| Reversing Alarm (Back vehicle) | √ |
