• Model NO.：SEM652D
• Type：Medium-sized Loader
• Operating Weight：16800kg
• Bucket Capacity：2.7cbm
• Engine：Weichai
• Engine Power：162kw
• Transport Package：Nude Package
• Specification：5ton
• Trademark：SEM
• Origin：China

Operating SpecificationsBreakout Force (GRD)kN173Dump Clearancemm3 113Articulated Angle°38±1TransmissionTransmission Type/Countershaft, power shiftTransmission Gears/F4/R4Torque Converter Type/Sigle stage 3 elementsMaker & Type/TR200Forward I/ Reverse Ikm/h8.6/8.6Forward II/ Reverse IIkm/h16/16Forward III/ Reverse IIIkm/h25/25Forward IV/ Reverse IVkm/h43/43AxleMain Drive Type/Spiral bevel gear, single stageFinal Drive Reduction Type/Planetary type, singe stageRear - Oscillating +/-°± 11EngineModel/WD10Rated PowerkW162Rated Speedr/min2 000DisplacementL9.726Implement HydraulicImplement System Type/Single load sensing flow sharing systemT w i n p u m p Boom Raise Times5.13Hydraulic Cycle Time (rated payload)s9.3System Presure SettingMpa18Brake SystemService Brake/Dry & caliper, air to oil controlParking Brake/Drum type shoe brake, spring applied & oil releasedSteering SystemSystem Type/Flow amplifyingSteering Pump Type/Piston pumpSystem Presure SettingMpa16Steering Angle (L/R)°38±1TiresSize/23.5-25Type/BiasLayer/16Textured Type/L3
