• Model NO.：LDS2000G
• Vibrating Amplitude：0.8mm
• Certification：ISO9001: 2000, CE, SGS
• Condition：New
• Color：Blue
• Hopper Volume：240L
• Hopper Rated Rev.：76r,Min
• Oil Tank：130L
• Hydraulic：Yes
• Usage：Dome Building, Swimming Pool etc.
• Application：Pumping,Grouting,Spraying,Plaster
• Power Option：Diesel, Electric, Gasoline
• Working Pressure：1.5 MPa (Chinese Hose),3.5 MPa (Trelleborg Hose)
• Max. Aggregate：10mm
• The Squeeze Hose：ID 50mm
• Transport Package：Seaworthy Packing: Plywood Box Shotcrete Machine
• Specification：CE, ISO
• Trademark：Leadcrete
• Origin：Henan, China
• Production Capacity：6-8m3,H

Item

Description

Working Pressure

1.5 Mpa (Chinese Hose)/3.5 Mpa (Trelleborg Hose)

Output

6-8m³/h

Max. Aggregate

10mm

The Squeeze Hose

ID 50mm

Conveying Hose

ID 50mm

Squeeze pump

GH50-680

Power

Honda GX390 Gasoline Engine (low pressure)

Honda GX630 Gasoline engine(high pressure)

Hopper volume:

240 Liter

Hopper rated rev.

76r/min

Oil tank

130 Liter

Requested air compressor

6m³/min, 0.6Mpa Pressure

Vertical Conveying Distance

15 m (Chinese Hose)/30 m (Trelleborg Hose)

Horizontal Conveying Distance

40 m (Chinese Hose)/80 m (Trelleborg Hose)

Weight

900kg

Overall Dimension

2350x1250x1450mm

 1.    For pumping/grouting/spraying mortar/plaster

2.    For pumping cellular light weight concrete

3.    For pumping of wet normal concrete, acceptable max. aggregate size is 10mm

After-Sales Service

During-sale service of used shotcrete machine

1. Acceptance of the product

2. Assist client product construction scheme

After sale service

1. Spare parts will be delivered as you need.

2. Engineers will go to clients' site for guiding the installation and test-running;

3. Warranty period: 12 months since the installation and commissioning;
