Grader Machine Gr165 XCMG Motor Grader 180HP Road Grader
XCMG E-Commerce Inc.- Certification：ISO, CE
- Condition：New
- Rated Power/Speed：132(2200r,Min)
- Ground Clearance：430mm
- Maximum Gradeability：25%
- Transport Package：Comply with Export Packaging Requirements
Base Info
- Model NO.：GR165
- Specification：8900x2625x3420mm
- Trademark：XCMG
- Origin：Jiangsu, China
- Production Capacity：10000 Unit,Units Per Year
Description
ItemGR165 Basic parameters Engine model 6BTA5.9-C180-II Rated power/speed 130kW/2200rpm Overall dimension (standard) 8900x2625x3470 Total weight (standard) 15000kg Tire specification 17.5-25 Ground clearance (front axle) 430mm Tread 2156mm Space of front and rear axles 6219 mm Performance parameters Forward velocity 5,8,11,19,23,38km/h Reverse speed 5,11,23km/h Tractive effort f=0.75 77kN Maximum gradeability 25% Tire inflation pressure 260kPa Working system pressure 16MPa Transmission pressure 1.3-1.8Mpa Working parameters Maximum steering angle of front wheel ±50° Maximum slant angle of front wheel ±17° Maximum oscillating angle of front axle ±15° Maximum oscillating angle of equilibrium box ±15° Maximum steering angle of frame ±27° Minimum turning radius 7.3m Scrape knife Maximum lift height 450mm Maximum cutting depth 500mm Maximum tilt angle 90° Cutting angle 28°-70° Angle of revolution 360° Length & chord height 3660x610mm Oil filling amount Coolant 50L Fuel tank 280L Engine 24L Transmission 38L Hydraulic oil 110L Drive axle 28L Balancing box 46 L
