• Model NO.：JC45
• Bucket Capacity(M3)：0.4
• Engine Model：490
• Dumping Height(mm)：2380
• Dumping Reach(mm)：700
• Wheelbase(mm)：991
• Bucket Width(mm)：1740
• Rated Power (Kw)：37
• Displacement (L)：2.67
• Max. Speed (Km/H)：12
• Transport Package：Container
• Specification：CE
• Trademark：SINOHENG
• Origin：China
• Production Capacity：500PCS,Month

Model
Main technical parameterJC45GAOverall operating height(mm)3980BHeight to bucket hinge pin(mm)3080CHeight to top of cab(mm)2140DHeight to bottom of level bucket(mm)2913EOverall length without bucket(mm)2640FOverall length with bucket(mm)3420GDumping angle at maximum height(°)40HDumping height(mm)2380IDumping reach(mm)700JRollback of bucket on ground(°)30KRollback of bucket at full height(°)104LWheelbase(mm)991MGround clearance(mm)185NAngle of departure(°)20OFront turning radius without bucket(mm)1168PFront turning radius(mm)1958QRear turning radius(mm)1630RRear axle to bumper(mm)1108STread width, centerline to centerline(mm) 1450TWidth(mm)1720UBucket width(mm)1740

Model	JC45
Engine model	490
Bore x stroke(mm)	95×106
Rated power (Kw)	37
Rotating speed(rpm)	2650
Number of cylinders	4
Max. torque (N.m)	156
Displacement  (L)	2.67
Max. Speed (km/h)	12
Tire(track) modei	10-16.5
Operating load(kg)	700
Lifting	Arc lifting
Bucket capacity(m3)	0.4
Rated flux(L/min)	75
High Flow Flux(L/min)
Fuel tank capacity(L)	65
Self weight bucket(kg)	3000
