Lds2000g Swimming Pool Small Shotcrete Machine for Sale
Zhengzhou Lead Equipment Co., Ltd.- Type：Shotcrete
- Shotcrete Type：Wet
- Machining Process：Hydraulic
- Structure：Spiral Type
- Productivity：6-8m3,H
- Feeding Height：1370mm
Base Info
- Model NO.：LDS2000G
- Vibrating Amplitude：0.8mm
- Certification：ISO9001: 2000, CE, SGS
- Condition：New
- Color：White
- Hopper Volume：240L
- Hopper Rated Rev.：76r,Min
- Oil Tank：130L
- Hydraulic：Yes
- Usage：Dome Building, Swimming Pool etc.
- Application：Pumping,Grouting,Spraying,Plaster
- Power Option：Diesel, Electric, Gasoline
- Working Pressure：1.5 MPa (Chinese Hose),3.5 MPa (Trelleborg Hose)
- Max. Aggregate：10mm
- The Squeeze Hose：ID 50mm
- Transport Package：Seaworthy Packing: Plywood Box Shotcrete Machine
- Specification：CE, ISO
- Trademark：Leadcrete
- Origin：Henan, China
- Production Capacity：6-8m3,H
Description
Item
Description
Working Pressure
1.5 Mpa (Chinese Hose)/3.5 Mpa (Trelleborg Hose)
Output
6-8m3/h
Max. Aggregate
10mm
The Squeeze Hose
ID 50mm
Conveying Hose
ID 50mm
Squeeze pump
GH50-680
Power
Honda GX390 Gasoline Engine (low pressure)
Honda GX630 Gasoline engine(high pressure)
Hopper volume:
240 Liter
Hopper rated rev.
76r/min
Oil tank
130 Liter
Requested air compressor
6m3/min, 0.6Mpa Pressure
Vertical Conveying Distance
15 m (Chinese Hose)/30 m (Trelleborg Hose)
Horizontal Conveying Distance
40 m (Chinese Hose)/80 m (Trelleborg Hose)
Weight
900kg
Overall Dimension
2350x1250x1450mm
