Hot Sale Foton Lovol FL936h 3 Ton Wheel Loader
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification：ISO, CE
- Condition：New
- Rated Load：3-6t
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：Fl936H
- Type：Small Loader
- Bucket Capacity：1.8 M3
- Rated Power：92 Kw
- Max. Speed：39km,H
- Operating Weight：10300kg
- Transport Package：Container
- Specification：7997*3000*3290mm
- Trademark：TOP BRAND
- Origin：China
- HS Code：84295100
- Production Capacity：100units,Month
Description
Specification
Model NO.
Rated load
Ton
3
Total weight
Kg
10000kg
Reted bucket capacity
M3
1.8
Max gradeability
25 degree
Dumping height
mm
3200
Overall dimensions
mm
5600*1900*2650
Min turning radius
mm
5000
Engine
Model
YUNNEI 490
Type
In-line,water colled,four stroke
Direct injection,four-cylinder
Rated power
kw
60
Rated speed
rpm
2200
Transmission
Gear box
Contershaft powershift gearbox
Torque convert
240
Gear shift
2F2R
Max speed
km/h
25
Axle model
ISUZU
Wheel base
mm
2200
Hydraulic system pressure
mpa
16
Rasing time
s
5.0
Total cycle time
s
10.5
Function of leveling automatically
yes
Brake system
Service brake
Hydraulic,expansion shoe brake on 4 wheels
Parking brake
Drum type shoe brake
Tyre
Tyre size
20.5-16
Front tyre pressure
mpa
0.3
Rear tyre pressure
mpa
0.28
