New Condition Se220LC 23ton 1.05m3 Bucket Capacity Hydraulic Pump Excavator for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.5~1.0m³
Base Info
- Model NO.：SE220LC
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
- Condition：New
- Trademark：SHANTUI
- Origin：China
Description
Basic Info.
Model NO. SE220LC Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Trademark SHANTUI Origin ChinaProduct Description
New Condition SE220LC 23Ton 1.05m3 Bucket Capacity Hydraulic Pump Excavator for SaleQuick and convenient maintenances
1. Supported by two cylinders, the backward-opening engine hood features handy opening, large opening angle, and easy maintenances.
2. The electric parts are centrally arranged to ease the checking and maintenances.
3. The filling of coolant, the replacement of air filter element, and the power master switch are easily accessible.
4. The parallel radiator effectively avoids the overheating and eases the cleaning.
5. The fuel filter element, engine oil filter element, and pilot filter element are centrally arranged so that all maintenances and replacements can be completed from on same position
6. The high-precision fuel filter element features powerful fuel adaptability and the electric fuel pumping function is provided for automatic fuel refilling and easy start.
Spacious and comfortable operating environment1. The colors of the injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.
2. The control devices are reasonably arranged to realize large space, broad vision, and convenient and comfortable operations.
3. The high-power A/C system and the air cushioned seat guarantee comfortable driving/riding.
Intelligent electronic control and optimal power control1. The intelligent control system realizes high match between power system and hydraulic system to improve the working efficiency and reduce the fuel consumption.
2. The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.
3. Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.
Enhanced working device1. The design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
2. The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
3. The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
| Comparative item | SE220LC |
| Overall dimensions | |
| Overall length (mm) | 9615 |
| Ground length (During transport) (mm) | 5025 |
| Overall height (To the top of boom) (mm) | 3035 |
| Overall width (mm) | 3180 |
| Overall height (To top of cab) (mm) | 3045 |
| Ground clearance of counterweight (mm) | 1055 |
| Minimum ground clearance (mm) | 466 |
| Tail turning radius (mm) | 2925 |
| Track length (mm) | 4460 |
| Track gauge (mm) | 2380 |
| Track width (mm) | 3180 |
| Standard track shoe width (mm) | 800 |
| Turntable width (mm) | 2725 |
| Distance from slewing center to tail (mm) | 2920 |
| Working range | |
| Maximum digging height (mm) | 10075 |
| Maximum dumping height (mm) | 7165 |
| Maximum digging depth (mm) | 6515 |
| Maximum vertical digging depth (mm) | 5795 |
| Maximum digging distance (mm) | 9865 |
| Maximum digging distance at ground level (mm) | 9685 |
| Working device minimum turning radius (mm) | 2970 |
| Engine | |
| Model | Cummins B5.9-C |
| Type | Water cooled, six cylinder in-line, turbocharged |
| Displacement (L) | 5.9 |
| Rated power (kW/rpm) | 112/1950 |
| Hydraulic system | |
| Type of hydraulic pump | Variable piston pump |
| Rated working flow (L/min) | 2x218 |
| Bucket | |
| Bucket capacity (m³) | 1.05 |
| Swing system | |
| Maximum swing speed (r/min) | 10.2 |
| Brake type | |
| Digging force | |
| Bucket arm digging force (KN) | 92.5 |
| Bucket digging force (KN) | 127 |
| Operating weight and ground pressure | |
| Operating weight (kg) | 22800 |
| Ground pressure (kPa) | 35.3 |
| Traveling system | |
| Traveling motor | Axial variable plunger motor |
| Traveling speed (km/h) | 3.2/4.7 |
| Traction force (KN) | 203 |
| Gradeability | 70% |
| Tank capacity | |
| Fuel tank capacity (L) | 330 |
| Cooling system (L) | 28 |
| Engine oil capacity (L) | 20 |
| Hydraulic oil tank/system capacity (L) | 400 |
