• Model NO.：Clg6526
• Certification：ISO 9001:2000
• Condition：New
• Max. Operating Mass：26000kg
• Min. Operating Mass：21000kg
• Tyre Inflation Pressure：400~725kpa
• Overlapping of Front&Rear Tyre：50mm
• Working Speed：0~8km,H
• Traveling Speed：0~20km,H
• Min. Ground Clearance：290mm
• Min. Outside Turning Radius：9000mm
• Transport Package：Nude Packing
• Specification：5700 *2420*3020(3220)mm
• Origin：Jiangsu, China
• HS Code：84294019
• Production Capacity：1000,PCS

Item  CLG6526     Mass (kg)            Max. Operating Mass26000  (kg)             Min. Operating Mass21000  (kPa)                Rolling Pressure250~420  (kg)                 Single Tyre Load2364  (kPa)                 Tyre Inflation Pressure400~725  (mm)                 Overlapping of Front&Rear Tyre50    Drive (km/h)             Working Speed0~8  (km/h)                   Traveling Speed0~20  (mm)          Compacting Width2750  (%)            Theoretical Gradeability20  (mm)                    Min. Ground Clearance290  (mm)                           Wheelbase3840  (°)                   Steering Angle±30  (mm)             Swing of Front Tyre±50  (mm)                   Min. Outside Turning Radius9000                          Tyre Type11.00-20-16PR                        Tyre Numbers56          Front 5 Rear 6  (mm)                      Overall Length4950  (mm)                     Overall Width2750  (mm)                      Overall Height3250     Engine                           BrandDF Cummins                            Model6BTA5.9-C180-II                          Emission RegulationTier  (kW)                       Rated Power132  (r/min)                       Rated Rotation Speed2200  (g/kW.h)                Theoretical Fuel Consumption232  (N.m)                        Max. Torque750                        Number of Cylinders6  (L)                    Displacement5.9                    AspirationTurbocharged                       Cooling TypeWaterHydraulicTravel Pump                           Brand                            Model  (mL)                         Displacement Travel Motor                               Brand                           Model  (mL)                        Displacement           Drive Axle                            BrandFenyi                            ModelPQ20.5A        Volume (V/Ah)                        Battery24/200  (V/A)                         Alternator28/70  (L)                   Drive Axle18  (L)               Booster Pump6  (L)                                Fuel Tank220  (L)                            Hydraulic Oil Tank60  (L)                        Engine Oil15  (L)                Transimission/Torque Converter27  (L)                           Coolant32  (L)                  Sprinkler Tank1000
