• Model NO.：HB37
• Vibrating Amplitude：1.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Red
• Max. Speed：90km,H
• Max. Engine Power：287kw
• Theoretical Output：138,90m3,H
• Max. Delivery Pressure：8.7,13MPa
• Transport Package：Nude
• Specification：11990*2490*3900
• Trademark：Oriemac
• Origin：China
• HS Code：8705909100
• Production Capacity：10units Per Month

No.ItemUnitParameter1Max. speedkm902Min. turning diameterm18.43Brake distancem74Approach angle°315Departure angle°126Chassis model CXZ51Q ( Japan )7Total weightkg2815081st axle loadkg678092nd, 3rd axle loadkg2122010Engine model 6WF111Max. Engine powerkW28712Max. Engine torqueN.m186213Max. grade-ability%3814Fuel consumption limitL/100km3415Outline dimensions (Length´ Width ´Height)mm11990´2490´3900



Technical Data for Pumping Operation




No.ItemUnitParameter1Theoretical outputm³/h138/902Max. delivery pressureMPa8.7/133Reach heightm37.44Reach depthm23.75Front outrigger transverse spanmm72806Rear outrigger transverse spanmm66007Outrigger longitudinal spanmm68608Delivery pipe diametermm1259Remote control distancem10010Placing boom slewing range°370
