Xs203j Mechanical Road Machine Single Drum Compactors
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Vibration
- Axle：Uniaxial Monowheel
- Grinding Wheel Type：Sheep Foot Roller
- Compaction Depth：40cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：XS203J
- Travel Speed：40cm,s
- Centrifugal Force：40KN
- Certification：CE, ISO 9001:2000
- Condition：New
- Transport Package：in Nude
- Specification：6430*2470*3260mm
- Trademark：ORIEMAC
- Origin：Jiangsu, China
- HS Code：8429401100
- Production Capacity：5000PCS,Year
Description
project
XS203
quality
Working weight (kg)
20000
Front wheel distribution weight (kg)
13500
Rear wheel distribution weight (kg)
6500
engine
model
SC7H190.1G3
Rated power (kW)
140
Rated speed (r / min)
2000
Compaction performance
Static linear pressure (N / cm)
621
Vibration frequency (Hz)
high frequency
33
Low frequency
28
Nominal amplitude (mm)
Large (at low frequencies)
1.86
Small (at high frequencies)
0.93
Excitation force (kN)
Large (at low frequencies)
370
Small (at high frequencies)
255
Driving performance
Speed (km / h)
file
0 to 3.4
file
0 to 5
file
0 to 5.2
IV file
0 to 10.4
Minimum turning outside radius (mm)
6500
Theoretical climbing ability (%)
50
Steering angle (°)
± 33
Swing angle (°)
± 10
size
Overall size (mm)
length
6523
width
2350
height
3200
Wheelbase (mm)
3210
Minimum ground clearance (mm)
466
Vibration wheel diameter (mm)
1600
Vibration wheel width (mm)
2130
