Backhoe Loader
Shandong China Machinery Co., Ltd.- Certification：CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic - Mechanical
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Type：Medium-sized Loader
- Transport Package：Wooden Box Packing
- Trademark：CNMC
- Origin：Shangond
- Production Capacity：100sets,Month
Description
The Performance Parameter of Backhoe Loader WZ25-18Overall Operating Weight 4500KG Transport Dimension L*W*H 6800x2100x2980mm Min. Ground Clearance 300mm Bucket Capacity 0.8m3 Loading Lifting Capacity 1800KG Bucket Dumping Height 200mm Backhoe Capacity(Width) 0.18m3 Max. Digging Depth 2600mm Engine Model YUNNEI YN27GBZ Turbo Type In Line,Direct injection,Four-Stroke,Water Cooling Rated Power 58KW Rated Speed 2400r/min Optional engine XINCHAI EURO3 or 5/YANMAR EPA3/CUMMINS EPA4 Steering System Steering Angle ±35 o Min. turning radius 4800mm Pressure of the system 12Mpa Axle Model Wheel hub reducer drive axle Drive type Four wheel drive Transmission System Torque Converter Model YJ265 Cooling Method Oil-cooling Pressure Circulation Gearbox Type Power Transmission Gears Two Gears Ahead, Two Gears Astern Max.Speed 28Km/h Optional Gears Four Gears Ahead, Four Gears Astern Max.Speed 33Km/h Tyre Model 23.5/70-16 Pressure of Front wheel 0.22 Mpa Pressure of Back Wheel 0.22 Mpa Brake System Service Brake Air Over Oil Caliper Brake External Type Self-regulation Self-balance Emergency Brake Operation Power Implementing brake Manual Operation Power Terminating Brake Hydraulic System Pressure of Hydraulic System 22Mpa
Pls contact us for more ...........
Pls contact us for more ...........
