XCMG Official Factory 21 Ton 0.86m3 Digger Excavator Xe210wb China Top Brand New Hydraulic Wheel Excavator Machine for Sale
XCMG E-Commerce Inc.- Type：Wheel Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Transmission：Hydraulic Transmission
- Bucket Capacity：0.86m3
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：XE210WB
- Condition：New
- Operating Weight：20500kg
- Maximum Digging Height：9000mm
- Maximum Digging Depth：6460mm
- Rated Speed：2050rpm
- Engine Brand：Cummins
- Power(W)：135kw
- Bucket Digging Force：144kn
- Trademark：XCMG
- Origin：Jiangsu, China
- Production Capacity：10000,Year
Description
Modelunit XE210WB Operating weight Kg 20500 Bucket capacity m³ 0.86 Engine Model / QSB7 No.of cylinders / 6 Rated power/speed kw/rpm 135/2050 Maximum torque/speed N.m 740/1200 Displacement L 6.7 Main performance Travel speed(H/L) km/h 31/9.5 Swing speed r/min 13 Gradeability ° ≤30 Arm digging force kN 100 Hydraulic System Main pump / Two piston pumps Rated flow L/min 2×220 Main safety valve pressure MPa 31.4/34.3 Travel system pressure MPa 31.4 Swing system pressure MPa 28 Pilot system pressure MPa 3.9 Oil Capacity Fuel tank capacity L 305 Hydraulic tank capacity L 202 Engine oil capacity L 17.5 Appearance Total length mm 9597 Total width mm 2552 Total height mm 3590 Width of platform mm 2490 Total width of chassis mm 2495 Wheel base mm 2850 Counterweight clearance mm 1250 Working scope Max. digging height mm 9000 Max. dumping height mm 7000 Max. digging depth mm 6460 Maximum depth cut for 2240mm(8 ft) level bottom mm 6285 Max.vertical digging depth mm 5810 Max. digging radius mm 9840 Min. swing radius mm 2820 Standard Boom Length mm 5700 Arm Length mm 2900 Bucket Capacity m³ 0.86
