Famous Brand Liugong 30 Ton Tire Roller
Maxizm Construction Machinery (Qingdao) Co., Ltd.- Type：Road Roller
- Object：Cement Concrete Pavement
- Moving Type：Mobile
- Mixing Method：Intermittent Compulsory
- Automatic Grade：Automatic
- Product Capacity：>400t,h
Base Info
- Model NO.：6530E
- Certification：ISO9001: 2000, CE
- Condition：New
- Single Tire Load：1778 Kg
- Overlapping of Front & Rear Tire：45 mm
- Rated Power：97 Kw (132 HP) @ 2200 Rpm
- Working Speed：0-7 Km,H
- Traveling Speed：0-16 Km,H
- Compacting Width：2250 mm
- Min. Ground Clearance：290mm
- Wheelbase：3600mm
- Min. Outside Turning Radius：8000 mm
- Tire Numbers：Front 4 Rear 5
- Transport Package：Nude
- Specification：4800 mm*2310mm*3270mm
- Trademark：Shantui
- Origin：China
- Production Capacity：5000
Description
Max. Operating Mass
16000 kg
Min. Operating Mass
11000 kg
Single Tire Load
1778 kg
Overlapping of Front & Rear Tire
45 mm
Model
4BTAA3.9-C130
Emission Regulation
Stage II
Rated Power
97 kW (132 hp) @ 2200 rpm
Working Speed
0-7 km/h
Traveling Speed
0-16 km/h
Compacting Width
2250 mm
Theoretical Gradeability
20%
Min. Ground Clearance
290 mm
Wheelbase
3600 mm
Min. Outside Turning Radius
8000 mm
Tire Type
11.00-20-16PR
Tire Numbers
Front 4 Rear 5
Overall Length
4800 mm
Overall Width
2310 mm
Overall Height
3270 mm
