Liugong 35ton Heavy Excavator 936e Hydraulics Hot Sale
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：936E
- Drive Type：Internal Combustion Drive
- Bucket Capacity：>1.5m³
- Size：Large-Scale
- Certification：ISO9001: 2000
- Condition：New
- Operating Weight with Cab：35000-35585 Kg
- Engine Power：186 Kw
- Maximum Travel Speed：5.5 Km,H
- Maximum Swing Speed：10 Rpm
- Arm Breakout Force：170 Kn
- Bucket Breakout Force：232 Kn
- Boom：6400 mm
- Transport Package：Nude Package
- Specification：11167*3190*3530MM
- Trademark：Liugong
- Origin：China
- HS Code：8429521200
- Production Capacity：1000units,Year
Description
Operating weight with cab
35000-35585 kg
Engine power
186 kW (249 hp) @ 2200 rpm
Bucket capacity
1.6 / 1.9 m³
Maximum travel speed (High)
5.5 km/h
Maximum travel speed (Low)
3.4 km/h
Maximum swing speed
10 rpm
Arm breakout force
170 kN
Arm breakout force Power boost
185 kN
Bucket breakout force
232 kN
Bucket breakout force Power boost
252 kN
Shipping length
11167 mm
Shipping width
3190 mm
Shipping height
3530 mm
Track shoe width (std)
600 mm
Boom
6400 mm
Arm
3200 mm
Digging reach
11100 mm
Digging reach on ground
10900 mm
Digging depth
7340 mm
Vertical wall digging depth
6460 mm
Cutting height
10240 mm
Dumping height
7160 mm
Minimum front swing radius
4465 mm
Model
Cummins 6C8.3
Emission
EPA Tier 2 / EU Stage II
System maximum flow
2×300 L/min (2x79 gal/min)
System pressure
34.3 MPa
