• Model NO.：909ECR
• Drive Type：Diesel
• Bucket Capacity：0.5~1.0m³
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight with Cab：8700 Kg
• Engine Power：46.2 Kw
• Maximum Travel Speed：2.4 Km,H
• Maximum Swing Speed：10.5 Rpm
• Bucket Breakout Force：63 Kn
• Boom：3375 mm
• Arm：1650 , 2100 mm
• System Pressure：28 MPa
• Dozer-up：470 mm
• Transport Package：Nude
• Specification：6200*2400*2710MM
• Trademark：Liugong
• Origin：Shandong, China
• HS Code：8429521200
• Production Capacity：1000pes,Year

Operating weight with cab

8700 kg

Engine power

46.2 kW (62.0 hp) @ 2200 rpm

Bucket capacity

0.14-0.4 m³

Maximum travel speed (High)

4.8 km/h

Maximum travel speed (Low)

2.4 km/h

Maximum swing speed

10.5 rpm

Arm breakout force

43 / 37 kN

Bucket breakout force

63 kN

Shipping length

6115 / 6200 mm

Shipping width

2400 mm

Shipping height

2710 mm

Track shoe width (std)

450 mm

Boom

3375 mm

Arm

1650 / 2100 mm

Digging reach

6847 / 7264 mm

Digging reach on ground

6651 / 7082 mm

Digging depth

4093 / 4540 mm

Vertical wall digging depth

3043 / 3963 mm

Cutting height

6724 / 7016 mm

Dumping height

4725 / 5000 mm

Minimum front swing radius

2421 mm

Dozer-up

470 mm

Dozer-down

510 mm

Swing boom left rotation

70 °

Swing boom right rotation

55 °

Model

Yanmar 4TNV98C-SLY

Emission

EU Stage IIIB / EPA Tier 4F

System maximum flow

196 L/min ( 52 gal/min)

System pressure

28 MPa
