CE Approved Joystick Controlled 5 Ton Wheel Loader

Shanghai YingXin World Machinery Co., Ltd.
  • Type：Wheel Loader
  • Bucket：Shovel
  • Transmission：Mechanical Transmission
  • Drive Type：Internal Combustion Drive
  • Bucket Capacity：>1.5m³
  • Size：Medium-Sized

Base Info

  • Model NO.：W156
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Wheel Loader：Wheel Loader Factory
  • Loader：Front Loader
  • Wheel Loader for Sale：Front End Loader
  • Machine Type：Wheel Loader 5ton
  • Application：Loading Machine, Earth Moving Machine
  • Rated Load：5000kg
  • Operation Weight：16500kg
  • Engine：C6121
  • Max. Travel Speed：37km,H
  • Tyre Size：23.5-25
  • Transport Package：Loose
  • Specification：W156
  • Trademark：WORLD
  • Origin：China
  • HS Code：84295100
  • Production Capacity：5000PCS,Year

Description

Diesel EngineBrandWeichai Steyr or Cat6121 or CumminsTypeDirect injection, turbocharged, water cooling, 4 strokes, 6 cylindersRated Output (kw)162/162/160Rated Speed (rpm)2200Max. Torque (N.m)855/860/908TransmissionTypePlanet typeRated Input Speed (rpm)2200Transaxle & TireRear Axle OscillationCenter oscillationOscillating Angle Of Rear Axle (°)13Pressure Of Tire (MPa)0.28-0.32Working Hydraulic SystemWorking Pump TypeGear pumpWorking Pressure (MPa)17Lifting Cylinder Bore x Stroke (mm)165x757Tilting Cylinder Bore x Stroke (mm)200x540Steering SystemSteering Pump TypeCBGJ2080Working Pressure (MPa)12Steering Cylinder Bore x Stroke (mm)100x342Max. Steering Angle (°)35
