• Model NO.：YL27-3
• Travel Speed：40cm,s
• Centrifugal Force：40KN
• Certification：EPA, CE, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Max.Operating Weight：27000kg
• Transport Package：Nude
• Specification：CE
• Trademark：Changlin
• Origin：Jiangsu, China
• HS Code：84294019
• Production Capacity：100 Sets,Month

Overall  Dimension1Length5060mm2Width2870mm3Height(To  the  top  of  the  cab)3480mm4Wheel  base3840mmMain  Technical  Specification1Max  Operating  weight27000kg2Min  Operating  weight15500kg3Max.   ballast  water4500  kg4Average  ground  press260-435kPa5Min.   ground  clearance250mm6Roller  width2750mm7Grade  ability≥ 208Min.   turning  radius(Outside  of  rear  wheel)9000mm9Traveling  speed(Km/h), 2  forward  and  2  reverse (1)  1st  gear  forward0~8 (2)  2nd  gear  forward0~16 (3)  1st  gear  reverse0~8 (4)  2nd  gear  reverse0~16Diesel  engine1ModelChinese  Engine  D6114ZG6B2TypeDirect  injection.   Turbocharged.   Water  cooling3Rated  output132  kW4Rated  speed2000(r/min)5Inter-bore  of  cylinder/stroke114  (mm)6Total  exhaust  of  cylinder8.3  (L)7Max.   Torque695(N. M)8Min.   specific  fuel  consumption226(g/Kw. h)9Model  and  parameter  of  starting  motorQD285KS/R7.5-24V10Starting  typeElectric11Net  weight640(kg)
