Top Brand 0.7m3 Bucket 1.2ton Small Wheel Loader Lw150fv
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：After Service,Online Contact , Spare Parts for Fre
- Warranty：One Year Warranty
- Certification：ISO, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
Base Info
- Model NO.：LW150FV
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Rated Power：45 Kw
- Wheel Base：2300 mm
- Dumping Clearance：3300 mm
- Key Word：Mini Wheel Loader
- Transport Package：Roro,Bulk,Nude,Container
- Specification：5.08*1.65*2.68m
- Trademark：TOP BRAND
- Origin：China
- HS Code：84295100
- Production Capacity：100units,Month
Description
Basic Info.
Model NO. LW150FV Load and Unload Mode Front Discharge Walking Mode Wheeled Type Medium-sized Loader Rated Power 45 Kw Wheel Base 2300 mm Dumping Clearance 3300 mm Key Word Mini Wheel Loader Transport Package Roro/Bulk/Nude/Container Specification 5.08*1.65*2.68m Trademark TOP BRAND Origin China HS Code 84295100 Production Capacity 100units/MonthProduct Description
Top Brand 0.7m3 Bucket 1.2ton Small Wheel Loader LW150FV1. LW150FV is a three-stage product independently developed , equipped with an electronically controlled high-pressure common-rail national three engine, high-quality split-type double-transformer, four-wheel drive, full hydraulic steering, strong power, high efficiency and higher environmental adaptability .
2. The hydraulic oil replacement cycle is extended to 2000 hours, far exceeding the level of the same industry, greatly reducing the user's use cost.
Performance specialty
1. Adopting long wheelbase (2300mm) design, adapting to various overweight working conditions, leading the industry in stability.
2. The unloading height of more than 3.3 meters can meet the needs of various occasions.
3. The whole oil cylinder and pin are treated by quenching and tempering process, leading in hardness and high reliability.
| Description | Specification | Unit |
| Rated operating load | 1200 | Kg |
| Bucket capacity | 0.7 | |
| Machine weight | 4350 | Kg |
| Dump clearance at maximum lift | 3300 | mm |
| Reach at maximum lift | 830 | mm |
| Wheel base | 2300 | mm |
| Tread | 1500 | mm |
| Max.breakout force | 28 | KN |
| Articulation angle | 35 | ° |
| Gradeability | 25 | ° |
| Tyre size | 16/70-16 | |
| Overall machine dimension L*M*H | 5890*1877*2835 | mm |
| Model | YN4A062-30CR | |
| Rated Power/Speed | 45/2400 | Kw/rpm |
| Travel Speed(I-gear F/R) | 8 | km/h |
| Travel Speed(II-gear F/R) | 20.5 | km/h |
