Shantui 30ton Rubber Tired Road Roller Sr30t with Good Price
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
Base Info
- Model NO.：SR30T
- Compaction Depth：40cm
- Engine Type：Diesel Engine
- Travel Speed：0-8km,H
- Centrifugal Force：200kn
- Certification：CE, ISO 9001:2000
- Condition：New
- Operating Weight (Kg)：30000
- Exciting Force (Kn)：200
- Vibration Frequency (Hz)：51,67
- Ground Pressure (Kpa)：200-460
- Gradeability (%)：20
- Engine Model：Sc7h
- Rated Power/Rated Speed (Kw/Rpm)：132,1800
- Wheelbase (mm)：3840
- Fuel Tank (L)：180
- Compacting Width(mm)：2750
- Transport Package：Container,RO-RO
- Specification：5060*2892*3338mm
- Trademark：SHANTUI
- Origin：China
- HS Code：8429401100
- Production Capacity：100units,Month
Description
Basic Info.
Model NO. SR30T Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 0-8km/H Centrifugal Force 200kn Certification CE, ISO 9001:2000 Condition New Operating Weight (Kg) 30000 Exciting Force (Kn) 200 Vibration Frequency (Hz) 51/67 Ground Pressure (Kpa) 200-460 Gradeability (%) 20 Engine Model Sc7h Rated Power/Rated Speed (Kw/Rpm) 132/1800 Wheelbase (mm) 3840 Fuel Tank (L) 180 Compacting Width(mm) 2750 Transport Package Container/RO-RO Specification 5060*2892*3338mm Trademark SHANTUI Origin China HS Code 8429401100 Production Capacity 100units/MonthProduct Description
SHANTUI 30Ton Rubber Tired Road Roller SR30T with Good Price
Product discription
Working performance
The high-strength three-point swing M frame for front wheels guarantees the uniform compacting on rugged ground.
The special tires for construction machinery feature good wear resistance and long life.
The hydraulic torque converter and power shift transmission with automatic stepless speed regulation are applied to achieve automatic adaptability and stable compacting drive of the road roller.
PARAMETER
| Parameter name | SR30T |
| Performance parameters | |
| Operating weight (Kg) | 30000 |
| Exciting force (KN) | - |
| Vibration frequency (Hz) | - |
| Nominal amplitude (mm) | - |
| Ground pressure (KPa) | 200-460 |
| Gradeability (%) | 20 |
| Engine | |
| Engine model | SC7H |
| Rated power/rated speed (kW/rpm) | 132/1800 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 5060*2892*3338 |
| Driving performance | |
| Forward speed (km/h) | F1:0-8,F2:0-18 |
| Reversing speed (km/h) | R1:0-8,R2:0-18 |
| Chassis System | |
| Wheelbase (mm) | 3840 |
| Tank capacity | |
| Fuel tank (L) | 180 |
| Working device | |
| Compacting width(mm) | 2750 |
