• Model NO.：SR28MR-3
• Compaction Depth：40cm
• Engine Type：Diesel Engine
• Travel Speed：0-4.82km,H
• Centrifugal Force：82,40
• Certification：CE, ISO 9001:2000
• Condition：New
• Operating Weight (Kg)：28000
• Exciting Force (Kn)：82,40
• Vibration Frequency (Hz)：42,48
• Ground Pressure (Kpa)：100-220
• Gradeability (%)：100
• Engine Model：Wp10g240
• Rated Power/Rated Speed (Kw/Rpm)：178kw,2200rpm
• Wheelbase (mm)：3500
• Fuel Tank (L)：450
• Compacting Width(mm)：3520
• Transport Package：Container,RO-RO
• Specification：7930*3660*3960mm
• Trademark：SHANTUI
• Origin：China
• HS Code：8429401900
• Production Capacity：100units,Month

Basic Info.

Model NO. SR28MR-3 Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 0-4.82km/H Centrifugal Force 82/40 Certification CE, ISO 9001:2000 Condition New Operating Weight (Kg) 28000 Exciting Force (Kn) 82/40 Vibration Frequency (Hz) 42/48 Ground Pressure (Kpa) 100-220 Gradeability (%) 100 Engine Model Wp10g240 Rated Power/Rated Speed (Kw/Rpm) 178kw/2200rpm Wheelbase (mm) 3500 Fuel Tank (L) 450 Compacting Width(mm) 3520 Transport Package Container/RO-RO Specification 7930*3660*3960mm Trademark SHANTUI Origin China HS Code 8429401900 Production Capacity 100units/Month

Product Description

China SHANTUI High Power Compactor Road Roller SR28MR-3 with Best PriceProduct discription
High Operating cost
The full-enclosed cab and the air purifier can guard the driver against the influence of severe working environment.

The traveling of machine is controlled by electronic control shifting joystick to achieve comfortable and handy operations, effectively mitigate operator's fatigue, and improve the operating efficiency.

The lifting of blade is controlled by electronic control joystick to achieve simple, flexible, and convenient operations.

The comfortable cushioned seat is adjustable in longitudinal position and is installed with left and right folding armrests and retractable seat belt and the A/C and heating system is installed to achieve safer and more comfortable operations.

The optical monitors within the cab are the safety guarantee for frequent reversing operations of the compactor.

PARAMETER

Parameter name	SR28MR-3
Performance parameters
Operating weight (Kg)	28000
Gradeability (%)	100
Engine
Engine model	WP10G240
Rated power/rated speed (kW/rpm)	178kw/2200rpm
Overall dimensions
Overall dimensions of machine (mm)	7930*3660*3960
Driving performance
Forward speed (km/h)	F1:4.82 ,F2: 7.66 ,F3:11.6
Reversing speed (km/h)	R1:4.82 ,R2:7.66
Chassis System
Wheelbase (mm)	3500
Tank capacity
Fuel tank (L)	450
Working device
Compacting width(mm)	3520

Pictures
