• Model NO.：FL936
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Operating Mass (Standard)：10070kg
• Bucket Capacity：1.8cbm
• Engine Model：Yc6b125-T20
• Rated Power：92,2200kw,Rpm
• Load and Unload Method：Front Discharge
• Transport Package：Nude Packing
• Specification：Within 15days delivery
• Trademark：Foton Lovol
• Origin：Shangdong, China
• HS Code：84295100
• Production Capacity：500 Set,Sets , Month

Complete machine parametersRated load(kg)3000Operating mass (standard)(kg)10070Bucket capacity(m³)1.8Boom lifting time(S)5.7Sum of three items(S)10.5Max. traction force(kN)92Max. breakout force(kN)120Running systemForward speed range(km/h)0-37Backward speed range(km/h)0-31.5Gearbox shiftFront : 4 gears rear: 2 gearsMax. gradeability(°)30Steering angle(°)36Tire model17.5-25-12PRService brakecaliper disc brakeParking brakeflexible shaft control caliper disc brakeTire center(mm)5131Outside of bucket(mm)6005Hydraulic systemWorking system pressure(Mpa)16Working system displacement(ml/r)63Steering system pressure(Mpa)14Steering system displacement(ml/r)63Hydraulic oil volume(L)110Working scopeOutline dimension(mm)7230×2424×3230Wheelbase(mm)2750Track(mm)1850Min. grounding distance (at hinge position)(mm)375Max. unloading height(mm)2990Unloading distance at max. unloading height(mm)1100Engine parametersModel(Yuchai)YC6B125-T20Type(Yuchai)Six-cylinder, in-line, direct injection, natural inspiration, and water coolingRated power(Kw/rpm)(Yuchai)92/2200Max. torque / speed(N.m/rpm)(Yuchai)463/1400-1600Cylinder bore x stroke(mm)(Yuchai)Φ108×125Displacement(L)(Yuchai)6.871Fuel consumption rate at rated working condition(g/Kw.h)(Yuchai)235Fuel tank capacityt(L)140Model(Weichai)Weichai WP6G125E22Type(Weichai)Six-cylinder, in-line, direct injection, turbocharging, and water coolingRated power(Kw/rpm)(Weichai)92/2200Max. torque / speed(N.m/rpm)(Weichai)500/1400-1600Cylinder bore x stroke(mm)(Weichai)Φ105×130Displacement(L)(Weichai)6.754Fuel consumption rate at rated working condition(g/Kw.h)(Weichai)225Model(Dongfeng Cummins)Dongfeng Cummins 6BT5.9-C130Type(Dongfeng Cummins)Six-cylinder, in-line, direct injection, turbocharging, and water coolingRated power(Kw/rpm)(Dongfeng Cummins)97/2200Max. torque / speed(N.m/rpm)(Dongfeng Cummins)560/1500Cylinder bore x stroke(mm)(Dongfeng Cummins)Φ102×120Displacement(L)(Dongfeng Cummins)5.9Fuel consumption rate at rated working condition(g/Kw.h)(Dongfeng Cummins)235
