• Model NO.：T160
• Engine Power：160HP
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Rated Power：117kw,2200rpm
• Overall Length：6104mm
• Horsepower：160HP
• Engine：Weichai
• Dozing Capacity：4.5m3
• Total Weight：17000kg
• Optional：Ripper
• Moving Type：Crawler
• Cab：Rops & Fops
• Blade Capacity：4.5-5m3
• Transport Package：Container or Bulk
• Specification：6104*3388*3032mm
• Trademark：LTMG
• Origin：China
• HS Code：84291190
• Production Capacity：2000 Sets,Year

EngineModel & type

Shangchai SC11CB184G2B1/Weichai WD10G178E25;

water-cooled, in-line, 4-stroke injection direct

Horsepower

Gross power: 131/175/1850 kW/HP/rpm //

Net power: 120/160/1850 kW/HP/rpm

Number of cylinders 6-126 x 130 mm (bore x stroke)Piston displacement 9.726 LMin. fuel consumption 214 g/kW·hMaximum torque765 N·m@1300 rpm

Power

 transmission

 system

Torque converter 3-element, 1 stage, 1 phaseTransmission Planetary gear type, power-shift, forced lubricationMain drive

Spiral bevel gear, single-stage speed reduction,

splash lubrication

Steering clutch

Lubricated, multi-disc, spring loaded, hand hydraulically separated, inter-linking with steering brake

Steering brake

Lubricated, floating band structure, foot brake

with hydraulic booster

Final drive2-stage speed reduction of spur gear, splash lubricationTravel speedGear 1st2nd 3rdForward0~3.29 km/h 0~5.82 km/h0~9.63 km/hReverse0~4.28 km/h0~7.59 km/h0~12.53 km/hUndercarriage
 systemTypeSprayed beam, suspended structure of equalizerCarrier rollers2 each sideTrack rollers6 each sideTrack type Assembled, single-grouserWidth of track shoes 510 mmPitch 203.2 mmHydraulic
SystemMaximum pressure 14 MPaPump type Gear pumpDischarge 243 L/min

Bore of

working cylinder × no.

110 mm × 2BladeBlade TypeStraight-tiltAngleU- BladeDozing capacity 4.5 m 3 4.4 m 35.0 m 3

Efficiency

(Theoretical value 40 m)

225 m 3 /h225 m 3 /h250 m 3 /hBlade width3388 mm3970 mm 3556 mmBlade height1149 mm 1040 mm1120 mm

Maximum drop

below ground

540 mm530 mm540 mmLifting height of blade1095 mm 1110 mm 1095 mmRiipper
(Optional)

Maximum digging depth

of 3-shank ripper

572 mm

Maximum lift

above ground

592 mmWeight of 3-shank ripper 1667 kg
Product Feature
 1.The Weichai electronic control, direct injection, turbocharged engine equipped features high torque reserve coefficient, excellent energy-conservation and environment-friendliness, and strong power. 2.The split transmission and torque converter system, single-turbine three-element torque converter, and AMT full-automatic electronic control transmission feature simple structure and higher reliability. 3.The electronic control joysticks feature convenient and flexible operations and incorporate the blade floating function. 4.The full-hydraulic maintenance-free wet drive axle features fast response, stable braking, and high safety and reliability.
