• Model NO.：LTW18
• Walking Mode：Wheeled
• Type：Underground Loader
• Overall Length：5650mm
• Max. Dumping Height：2200mm
• Tires Type：16,70-20
• Rated Power：60kw,66kw
• Optional：Air Conditioner, Glass Fork, etc
• Engine：Chinese Engine
• Engine Power：60,66 Kw
• Color：Could Be Decided by Buyer
• Tire：16,70-20
• Transport Package：Nude Packing, Fixed in Container
• Specification：5650mm*2000mm*2500mm
• Trademark：LTMG
• Origin：China
• HS Code：8429309000
• Production Capacity：500sets,Year

ModelLTW18Bucket capacity(m3)1.0Rated load(t)2.0Weight(t)5.8Traveling speed(km/h)0-24Forward gear I0-7Forward gear II0-24Reverse gearI 0-7  II 0-24Max climbing gradient300Overall length (mm)5650Overall width(mm)2000Overall height(mm)2500Wheel base(mm)2350Wheel tread(mm)1500Max dumping height(mm)2200Dumping reach(mm)1385Engine model4108/4105Rated power Kw60/66Tires type16/70-20

Product Features

Chinese 4108 or 4105 turbo charge engine, hydraulic transmission and hydraulic steering(model 280).

Wheel reduction axle, air over hydraulic break system .

Width less than 2.0m, height less than 2.5m, length less than 5.65m.

Narrow, low and short body suitable for ultra low and narrow roadway.

Optional: Three-way catalytic converter, wheel protection chains.

Optional: side dump bucket.

After sales service

LTMG always treat after-sale service as important the same as product quality.

LTMG grants our clients a twelve-month-period or 2000 working hours warranty for any machine purchased from us.

LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.

FAQ

1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.
Some of our products meets the EPA requirements.

2.Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first.
Details to see the LTMG warranty policy for each model.

4.Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5.What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is from 7 days to 90 days.
