• Model NO.：LT12J
• Walking Mode：Wheeled
• Type：Medium-sized Loader
• Engine：Wd10g270e201
• Max.Dumping Height：3600mm
• Brand：Ltmg
• Rated Power：178kw,2200rpm
• Overall Length：8600mm
• Tire Type：26.5r25
• Wheel Base Method：3550mm
• Engine Power：147~515kw
• Color：Yellow
• Transport Package：Nude Packing, Fixed in Container
• Specification：8600*3130*3550mm
• Trademark：LTMG
• Origin：China
• HS Code：8429510000
• Production Capacity：800sets,Year

ModelLT12JOperating weight 22,000kgEngine modelWD10G270E201Rated engine power178KWRated rotate speed2200r/ninMax.torque920N.mMax.dumping height3600mmRated load12,000 KGNO.of shiftsForward 4 For Reverse 2Driving speed  Forward/Reverse 10-6.5km/hForward/Reverse 20-12.3km/hForward/Reverse 30-24km/hForward/Reverse 40-41km/hGrade ability≥25°Turning angle 35°±1°Overall length 8600mmOverall width 3130mmOverall height 3550mmWheel base3550mmTrack base 2510mmTorque converter Model: YJ375X3 ratio:3.166Cycling time 14sTire type 26.5R25



Product Features

1).Powerful engine: Weichai engine, with global service all around the world. Turbocharged Intercooled, with multinomial patents, high efficiency low noise and cooling technology, strong power, energy conservation and environmental protection.

2).Transmission and torque converter:Chinese Beilian advance gearbox with Caterpillar technique transmission, The powerful electronic control countershaft transmission is easy to maintain, superior in the efficiency delivery and overload adaption.

3) Axle: Reinforced 60 axle with bigger axle hub/gears features 50% stronger bearing capacity than the normal ones and can forbid the oil leak efficiently, high reliability and convenient to maintenance. .

4). Tires:Enhanced front tires specially designed for the poor road conditions in mines. Steel radial tires are optional

5)Frame: Same design and dimensions with Japanese Komatsu 470 wheel loader. thicken hinge plate. makes the loader more durable and efficient. The thickness of the lifting arm is 60mm, the thickness of hinge pin is 80mm. much stronger than other Chinese manufacturers.

6)Durable:Floating forks, tire chain, log grapple, block fork, snow blade, grass fork, enlarged bucket and teeth etc.







After sales service

LTMG always treat after-sale service important as the same as product quality.
LTMG grants our clients a twelve-month-period or 2000-hours warranty for any machine purchased from us.
LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity
