Official Multifunctional 6m Asphalt Concrete Paver RP603L
Cruking Engineering Equipment (Xiamen) Co., Ltd.- After-sales Service：Video Technical Support, Online Support
- Warranty：1 Year
- Type：Paver
- Object：Soil Surface
- Moving Type：Mobile
- Mixing Method：Intermittent Compulsory
Base Info
- Model NO.：RP603L
- Automatic Grade：Automatic
- Product Capacity：400t,H
- Certification：ISO9001: 2000, CE
- Condition：New
- Dimension(L*W*H)：6590*2600*3942mm
- Power：103kw
- Weight：19000 Kg
- Basic Working Width：2.7m
- Hopper Capacity：13ton
- Travel Speed：0-15km,H
- Maximum Working Condition Quality：12.9t
- Diesel Tank Capcity：140L
- Paving Speed：0-15m,Min
- Max. Working Width：6m
- Max. Paving Thickness：260mm
- Basic Pave Width：2.7-4.75m
- Gradeability：20%
- Driving Speed：3km,H
- Vibrator Speed：0~1470r,Min
- Transport Package：Nude Packing
- Specification：6590*2600*3942mm
- Trademark：Asphalt Concrete Paver
- Origin：Jiangsu, China
- HS Code：8479102100
- Production Capacity：1000 Unit,Units Per Month
Description
Product OverviewProduct Paramenters
Product Configuration
Company Information
| Item | Unit | Parameter |
| Engine manufacturer | - | SDEC |
| Engine Model | - | SC4H140G3 |
| Rated Power | kW/rpm | 103/2200 |
| Operating weight | kg | 16500 |
| Overall dimensions | mm | 6660×2600×4000 |
| Basic Pave Width | m | 2.5~4.75 |
| Maximum Pave Width | m | 6 |
| Maximum L ayer Thickness | mm | 260 |
| Maximum Paving Speed | m/min | 17 |
| Maximum Travel Speed | km/h | 15 |
| Theoretic productivity | t/h | 400 |
| Hopper Capacity | t | 13 |
| Gradeability | % | 20 |
| Heating of screed | - | Electric/Gas heating |
| Travel type | - | tire |
