• Model NO.：LT40
• Type：Large Loader
• Operating Weight：39.6 T
• Max. Lifting Height：3300mm
• Fork Size：1600*mm350*mm135mm
• Wheelbase：4200mm
• Engine：Cummins,Weichai
• Tire Type：29.5-25
• Rated Power：247kw,2200rpm
• Max.Dumping Height：3300mm
• Color：Yellow or Customized
• Optional：Tyre Protection Chain, Air Conditioner, etc
• Transport Package：40gp+20gp
• Specification：10180mm*3450mm*3900mm
• Trademark：LTMG
• Origin：China
• HS Code：84295100
• Production Capacity：300sets,Month

Model LT40TOperating weight kg39,600Engine model WD12G336E211Rated engine powerKW247Rated rotate speedr/min2200Max.torqueN.m1350Max tractionKN≥191Max.dumping heightmm3300Rated loadT40Driving speed  Forward/Reverse 1km/h0-6.5Forward/Reverse 2km/h0-9Forward/Reverse 3km/h0-20.5Forward/Reverse 4km/h0-36.5Grade ability°≤25Turning angle 35°±1°Overall lengthmm10180Overall widthmm3450Overall heightmm3900Wheel basemm4200Track basemm3200dimension of forkmm1600*350*135Cycling timeS19.7Tire type 29.5-29

Product Features

1.Exclusive patent:
6 proprietary technologies are applied in our loaders make them more fuel-efficient and safety,
such as Auto Cooling Technology on brake system improve the safety.
And the dust-proof layer make the axle more durable.

2.Details in structure:
Bigger hinge pin and hinge bearing raise the carrying capacity, machine more powerful.
The exclusive dust-proof layer and sealed articulated points make the loader more durable.

3.Novel appearance and humanized design:
Cabin with broad view. Single (double)-handle pilot control system, electronic control gearshift to ensure easy operation and more comfortable.

4.Hydraulic systems:
To adopt confluence of double pumps and equivalents unloading hydraulic systems, rational use of engine power, reduce energy consumption effectively. Independent transmission oil and hydraulic oil cooling improve the hydraulic system stability.

5.Optional attachment:
Floating forks, tire chain, log grapple, block fork, snow blade, grass fork, enlarged bucket and teeth etc.


Packing&Shipping





After sales service

LTMG always treat after-sale service important as the same as product quality.
LTMG grants our clients a twelve-month-period or 2000 working hours warranty for any machine purchased from us.
LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity

FAQ

1.What the Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.

2.Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4.Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5.What the payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is from 7 days to 90 days.
