12 Ton Double Drum Compactor Xd122e Road Roller

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.
  • Type：Road Roller
  • Working Method：Vibration
  • Axle：Biaxial Dual-Drum
  • Grinding Wheel Type：Slot Grind
  • Compaction Depth：40cm
  • Engine Type：Diesel Engine

Base Info

  • Model NO.：XD122E
  • Travel Speed：40cm,s
  • Centrifugal Force：40KN
  • Certification：CE, ISO 9001:2000, ISO 9001:2008
  • Condition：New
  • Transport Package：Nude
  • Specification：98kw
  • Trademark：ORIEMAC
  • Origin：Shanghai China
  • HS Code：84294019
  • Production Capacity：1000 Units Per Month

Description


Type
Unit
XD122E
Operating weight (including cab)
kg
12300
load on front drum
kg
6150
Load on rear wheels
kg
6150
Static linear load
N/cm
295/295
Speed
km/h
0~10
Gradeability in theory
%
30
Minimum turning radius
mm
4770/6900
Crab-walking distance
mm
160
Minimum ground clearance
mm
340
Wheel base
mm
3700
Steering angle
± °
35
Swing angle
±°
8
Vibration frequency
Hz
45-48
Nominal amplitude
mm
0.41/0.8
Centrifugal force
kN
85/140
Model and manufacturer

DEUTZ BF4M2012C
Rated rotating speed
r/min
2300
Rated power
kW
98
Rated oil wear
g.kw/h
205
Water tank capacity
L
2×450
Fuel tank capacity
L
210
