• Model NO.：LG855N
• Type：Large Loader
• Transport Package：Nude Package
• Specification：5TON
• Trademark：lonking

Overall DataSteering SystemBucket Capacity (m3)3TypeHydraulic Load Sensing SystemRated Payload(kg)5000Cylinders-bore×Stroke(mm)2-100×324Operating Weight(kg)17300±300Steering PumpGear PumpTraction Force(kN)155±3System Pressure(MPa)15Breakout Force(kN)170±3Flow Rate(L/min/rpm)176/2200L×W×H(mm)8050×3034×3530Steering Angle±35°Travel Speeds (km/h):Hydraulic System II   Lift Cylinders-bore×Stroke(mm)2-180×721Forward11.536  Tilt Cylinder-bore×Stroke(mm)1-200×563Reverse16   Model of Implement PumpGear PumpEngine        WD10G220E21 DF CUM 6CTAA8.3-C215Flow Rate(L/min/rpm)220/2200Rated Power(kW·hp/rpm)162·(220)/2200160·(215)/2200System Pressure(MPa)16Peak Torque(Nm/rpm)860/1400-1600908/1500Pilot Control System Pressure(MPa)2.5Starting Voltage(V)24Hydraulic Cycle Time, Rated Load in Bucket(In second):Drive TrainRaise(Loaded)DumpLower(Empty)TotalTorque ConverterSingle-stage, Duo-turbine, 4-element61411Torque Ratio4Electrical SystemTransmissionPlanetary Powershift TransmissionSystem Voltage(V)24Gear2F/1RBattery (2 in series)(Ah)2-120Pressure of Transmission(MPa)1.2~1.5Lamp Voltage(V)24Main ReducerSpiral Bevel, 1-stage ReductionService Refill CapacityFinal ReducerPlanetary ReductionFuel Tank(L)285Tire23.5-25 L-3 16PR TTHydraulic Tank(L)270Brake SystemCrankshaft(L)20Service BrakeDuo Circuit Caliper,Dry BrakeTransmission(L)45Setting Pressure (MPa)0.70-0.78Front Axle(L) /Rear Axle(L)25/25Parking BrakeAir Actuated Caliper BrakeAir Conditioning SystemEmergency BrakeAir Actuated Caliper BrakeHeating Capacity(W)5800 (±10%) Cooling Capacity(W)4500 (±10%
