• Model NO.：WLFM51-190-760
• Numbers of Stations：25 Stations
• Type of Cutting：Roll-Formed and Length-Set Profile Cutting
• Main Motor Power：18.5kw
• Hydraulic Station Power：4kw
• Transport Package：Packing with Protection Foaming
• Specification：CE Standard, ISO 9001: 1008
• Trademark：WILLING INT′L
• Origin：China
• HS Code：84552210
• Production Capacity：150 Sets Per Year

Material specificationAluzinc steel and galvanized steel.Thickness0.8 mm to 1.5mmMain motor power18.5 kwHydraulic station power4 kwYield stress235Mpa (33KSI) ~ 350Mpa (50KSI)Roll forming speed12 m/minuteCutting tolerance+/-2.5mm(length≤5000mm);+/-3.0mm(5000mm<length≤10000mm).Manual uncoilerMax. Capacity: 8'000kgsVoltageAs per customer's requestNumbers of stations25 stationsType of cuttingRoll-formed and length-set profile cutting
3.Material of Main Equipment:Roller MaterialHigh grade S45C forged steel, coated with hard chrome.Active Shaft MaterialHigh grade S45C carbon wrought steel, diameter 85mm.Electric ElementsPLC control console, touch screen and transducer, from Mitsubishi, Japan.
Other elements, from Schneider Electric, Germany.Cutter bladesCr12MoV steel with quenched treatment, hardness HRC58~61,
wear-resistance, good steel structure, long life.
4.Process Sketch:
Uncoiling the shee t;  Infeed guiding ;  Roll forming ;  Measure length ;  Cutting the panel ; Panels to the supporter .

5.Standard Equipment of Machine:1)Manual Uncoiler1set2)Infeed Guide1set3)Roll Forming Station1set4)Post-cut Equipment1set5)Hydraulic Station1pc6)PLC Control Console1pc7)Product Support Table2pcs8)Spare Parts1box
Sales condiction
 1.Port of Shipment: Shanghai, China.
2.Port of Destination: as per customer's request.
3.Delivery time: 60 days.
4.Terms of Payment: 1) 30% for down payment by T/T; 70% for balance by T/T before shipment.
2) 100% Irrevocable L/C at sight.
5. Shipping Documents:
1) Bill of Lading, one full set; 2) Commercial invoice, triplication, 3) Packing list, triplication.
6. Insurance: covered by the buyer.
