• Model NO.：As to your request
• Trademark：WILLING INT
• Origin：China
• Production Capacity：150 Sets Per Year

Material specificationAluzinc steel and galvanized steel.Thickness0.8 mm to 1.5mm.Main motor power18.5 kw.Hydraulic station power4 kw.Yield stress235Mpa (33KSI) ~ 350Mpa (50KSI).Roll forming speed12 m/minute.Cutting tolerance+/-2.5mm(length≤5000mm); +/-3.0mm(5000mm<length≤10000mm).Manual uncoilerMax. Capacity: 8'000kgs.VoltageAs per customer's request.Numbers of stations25 stations.Type of cuttingRoll-formed and length-set profile cutting.
3.Material of Main Equipment:Roller MaterialHigh grade S45C forged steel, coated with hard chrome.Active Shaft MaterialHigh grade S45C carbon wrought steel, diameter 85mm.Electric ElementsPLC control console, touch screen and transducer, from Mitsubishi, Japan.
Other elements, from Schneider Electric, Germany.Cutter bladesCr12MoV steel with quenched treatment, hardness HRC58~61,
wear-resistance, good steel structure, long life.
4.Process Sketch:
Uncoiling the shee t;  Infeed guiding ;  Roll forming ;  Measure length ;  Cutting the panel ; Panels to the supporter .

5.Standard Equipment of Machine:1)Manual Uncoiler1set2)Infeed Guide1set3)Roll Forming Station1set4)Post-cut Equipment1set5)Hydraulic Station1pc6)PLC Control Console1pc7)Product Support Table2pcs8)Spare Parts1box
