• Model NO.：W156
• Log Loader：Wood Grapple
• Front Loader：Wheel Loader with Grapple
• Engine Brand：Cummins or Cat C6121
• Tyre Size：23.5-25
• Usage：Universal Type
• Engine Power：147~515kw
• Scraper Type：Tractor-Scraper
• Load and Unload Method：Front Discharge
• Color：Yellow
• Transport Package：in Container
• Specification：ce
• Trademark：WORLD
• Origin：China
• HS Code：84295100
• Production Capacity：5000 PCS,Year

Basic DataBucket Capacity3.0 or 3.6m³Rated Load5000kgTravelling SpeedForward 1st0-11.5km/hForward 2nd0-37.5km/hReverse 1st:0-17km/hMax. Traction165kNMax. Break Out Force150kNMin. Turning Radius (outside tires)6700mmMax. Dumping Height3100mmMax. Reach1200mmTotal Hydraulic Cycle Time≤11.1sFull Bucket Lifting Time5.7sDimensions (LxWxH)8075x2980x3500mmMin. Clearance Over Ground450mmOperating Weight16200kg

 Diesel EngineModelCUMMINS 6CTA8.3 or C6121 or WEICHAI WD10GTypeDirect injection, turbocharged, water cooling, 4 strokes, 6 cylindersRated Output162/162/160kWRated Speed2200rpmMax. Torque860/860/908N.m

 Transmission ModelZL50ManufacturerHangzhou Advance Gearbox Group Co., LtdRated Input Power154kWRated Input Speed2200rpmHydraulic Torque Converter ModelSingle stage, two phase four componentsTorque Ratio When Zero Speed4Transmission Typetwo forward and one reverse gears/power shift, planet type

 Mechanical Gear RatiosGear I2.4346Gear II0.6532Reverse1.7814

 I.O. Gear Ratio Of P.T.O.P.T.O. 11.00P.T.O. 21.167Hydraulic Oil Pressure:1.10-1.40MPaTorque Convertor Inlet Oil Pressure0.30-0.45MPaTorque Convertor Outlet Oil Pressure0.20-0.30MPaLubricating Oil Pressure0.10-0.20MPaMax.Permissible Temp.120ºC

 Transaxle & TyreTransaxle Typeself-made by Meritor technologyDrive System4 wheel driveDrive Ratio22.85Rear Axle OscillationCenter oscillationOscillating Angle Of Rear Axle                         13°Carrier Assembly Reduction Ratio4.625Rear Reduccer Reduction Ratio4.94Tyre Size23.5-25-16PRPressure Of Tyre0.28-0.32MPa

 Working Hydraulic SystemWorking Pump TypeGear PumpSystem Working Pressure17 MPaWorking Pump Max. Flow Rate328 l/minLifting Cylinder Bore x Stroke165x757mmTilting Cylinder Bore x Stroke200x540mm

 Steering SystemTypeArticulation, full hydraulic power steering system with flow-amplified systemSteering Pump Typegear pump (Model: CBGj2080)Max. Flow Rate43L (1920r/min)Max. Working Pressure12MPaSteering Cylinder Bore x Stroke100x342mmMax. Steering Angle35°

 Brake SystemTypeAir over hydraulic disc on four wheels brakesDrive Brake System Pressure0.71-0.784MPaParking Brakeinner expanding shoe brake, drum type, hand control

 Oil Injection CapacityFuel Tank300LEngine Oil30LTransmission45LHydraulic Oil Tank200LTransaxle30L
