• Model NO.：W2150-8
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Hydraulic Excavator：Excavator 150
• Excavator Engine Power：100HP
• Bucket Width：854mm
• Track Width：500mm
• Operation Weight：13600kg
• Hydraulic Pump：Kawasaki
• Travel Speeds：5.5km,H
• Max. Digging Depth：5532mm
• Max. Digging Height：8640mm
• Max. Dumping Height：6139mm
• Transport Package：Export Package
• Specification：CE, ISO
• Trademark：WORLD
• Origin：China
• HS Code：84295212
• Production Capacity：500PCS,Year

Working SpecificationsOperating weight 13600(Kg) Bucket capacity 0.6(m3) Max. breakout force (1)Bucket digging force 91.8(KN) (2)Arm digging force 65.3(KN) Max. digging height 8640(mm) Max. dumping height6139(mm) Max. digging depth 5532(mm) Max. vertical wall digging depth 5102(mm) Max. digging reach 8330(mm) Min. front swing radius 2500(mm) Max. pulling force 113(kN) Max. travel speed(double modes) 3.1/5.3(km/h) Max. grade ability 70%

 Overall dimensionsLength(with bucket on ground) 8330(mm) Width2490(mm) Bucket width 854(mm) Ground length (in transportation) 7718(mm) Height(To the top of the boom) 2800(mm) Height(To the top of the cab) 2705(mm) Counter weight ground clearance 885(mm) Track gauge 1990(mm) Tail swing radius 2380(mm) Min. ground clearance 392(mm) Rotating platform width 2490(mm) Counter weight height 930(mm) Crawler teeth thickness 25(mm) Reach from swing center to tail 2380(mm) Crawler ground length 2840(mm) Standard arm length 3132(mm) overall length of crawler 7525(mm)
