New Motor Grader Gr215 Road Equipment
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Grader
- Object：Gravel Road
- Moving Type：Mobile
- Mixing Method：Continuous Drum
- Automatic Grade：Automatic
- Product Capacity：40～400t,h
Base Info
- Model NO.：GR215
- Certification：ISO9001: 2000, CE
- Condition：New
- Application：Road Construction
- Transport Package：N,P
- Specification：CE
- Origin：Jiangsu, China
- HS Code：84292090
- Production Capacity：60sets, Month
Description
GR215Basic specification Engine model 6CTAA8.3 6CTA8.3 Rated power/speed 153kW/2200rpm 160kW/2200rpm Dimension(LxWxH) 8970× 2625× 3470mm Operating weight(Standard) 16500kg Performance specification Travelling speed, forward 5811192338 km/h Travelling speed, reverse 51123 km/h Tractive force(f=0.75) 82KN Max. gradeability 20% Tire inflation pressure 260 kPa Working hydraulic pressure 16 MPa Transmission pressure 1.31.8MPa Operating specification Max. steering angle of front wheels ± 50° Max. lean angle of front wheels ± 17° Max. oscillation angle of front axle ± 15° Max. oscillation angle of balance box 15 Frame articulation angle ± 27° Min. turning radius using articulation 7.3m Biade Maximum lift above ground 450mm Maximum depth of cutting 500mm Maximum blade position angle 90° Blade cutting angle 28° 70° Circle reversing rotation 360° Moldboard width X height 4270× 610mm
