• Vibrating Amplitude：2.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：White
• Transport Package：in Nude
• Specification：12500*2500*4000mm
• Trademark：Zoomlion
• Origin：China
• HS Code：9001100001
• Production Capacity：5000PCS,Year

ModelUnit38X-5RZPump UnitMax. Theor. output                       m³/h140/90Rated working pressure                      MPa35Pumping frequency                             min-127/17Hopper    capacity                                   L550Filling height                                   mm1540Hydraulic system type opened loopDistribution valve S valveOil cylinder dia.×stroke                   mmφ130×2100Concrete cylinder    dia.×stroke            mmφ230×2100Hydraulic oil cooling Wind coolingRecommended concrete slump                    cm12~23Max. aggregate dimension                    mm40Boom    SectionStructure type 38X-5RZPlacing depth                               m38Max. horizontal distance                       m34Max. placing depth                          m24.9Slewing angle ±270°Boom number 5The length of boom section                      mm8890/8100/8105/5405/3500Sections folding angle 90°/180°/180°/250°/90°Pipe diameter                                mm125End hose length                            mm3000Min. height of opening placing boom        mm9610Outriggers span     (front×rear×side) mm6190×8345×7045Upper StructureUpper Structure Mass                  kg15260Dimensions(L×W×H)mm9845×2500×3596Product Pictures
