Lutong Road Equipment Ltd210h 10 Ton Full Hydraulic Road Roller
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Three-Wheel
- Grinding Wheel Type：Sheep Foot Roller
- Compaction Depth：40cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：LTD210H
- Travel Speed：40cm,s
- Certification：ISO 9001:2000
- Condition：New
- Operating Mass：10000kg
- Static Linear Load：285n,Cm
- Vibrating Amplitude：1.8,0.9mm
- Vibrating Frequency：29,35Hz
- Max. Travel Speed：12km,H
- Turning Radius：6500mm
- Ground Clearance：472mm
- Vibration Drum Width：2100mm
- Drum Rim Thickness：24mm
- Wheelbase：3160mm
- Transport Package：Nude Packing
- Specification：5900 * 2280*3050mm
- Origin：Jiangsu, China
- HS Code：84294019
- Production Capacity：1000,PCS
Description
MODEL
LTD210H
Operating mass
Kg
10000
Static linear load
N/cm
285
Vibrating amplitude
Mm
1.8/0.9
Vibrating frequency
Hz
29/35
Centrifugal force
KN
240/120
Max. Travel speed
Km/h
12
Grade ability
%
35
Turning radius
mm
6500
Overall dimension
mm
5820x2278x3050
Ground clearance
mm
472
Vibration drum width
mm
2100
Drum rim thickness
mm
24
Wheelbase
mm
3160
Diesel model
6BT5.9
Diesel power
Kw
110
