• Model NO.：CDM856
• Type：Medium-sized Loader
• Model：Construction Equipment Wheel Loader Cdm856
• Bucket Capacity：3 Cbm
• Operating Weight：17500 Kg
• Engine：Weichai,Wd10g220e21
• Rated Power：162kw,2200rpm
• Rated Torque：860 N.M,1400rpm
• Wheel Base：3230 mm
• Load and Unload Method：Front Discharge
• Color：Yellow
• Warranty：1 Year
• Transport Package：40 Hq
• Specification：ISO, CE
• Trademark：Lonking
• Origin：Shanghai, China
• HS Code：84295100
• Production Capacity：1000sets,Month

NO.DESCRIPTIONUNITDIMENSIONSAOverall Height - Bucket Raisedmm5323BBucket Pin Height at Max. Liftmm4163CDump Clearance at Max. Lift ( 45°) mm3080DReach at Max. Lift and 45° Dumpmm1256ERack Back Angle at Carry°49.3FRack Back Angle at Ground°46GDigging Depthmm50HRack Back Angle at Max. Lift°58.3IDump Angle at Max. Lift°45JCarry Heightmm400KGround Clearancemm409LCenter Line of Front Axle to Hitchmm1615MWheel Basemm3230NOverall Lengthmm8100ODeparture Angle°32.6PHeight to Top of Cabmm3380QOverall Width over Bucketmm3010RMin. Turning Radius over Bucket mm7240SMin. Turning Radius over Tiresmm6537.5TSteering Angle - Left/Right°35UWidth at Tread Centermm2240VOverall Width over Tiresmm2835 OVERALL DATABucket Capacity3.0m³Rated Payload 5000kgOperating Weight17300±300kgTraction Force155±3kNBreakout Force170±3kNL×W×H8100×3010×3380mm ENGINE&ELECTRICAL SYSTEMMaker/ModelWEICHAI/WD10G220E21Emission StandardEPA (Tier II)/National IIEngine Type4 Stroke,Turbocharged,Water-cooled,Direct Injection,Diesel EngineRated Power162kW(220hp)/2200rpmMaximum Torque860N·m/1400-1600rpmBore x Stroke (mm)126×130No. of Cylinders/Displacement6/9.726LCompression Ratio17Air CleanerThree Stage Air Cleaner with Cyclone Pre-cleanerAlternator 55AmpBattery2-24V/120AhStarting Motor24V/7.5kWHeating Capacity (W)5000WCooling Capacity (W)4700W DRIVE TRAIN Transmission TypePlanetary Powershift TransmissionShift TypeMechanical Powershift ControlPressure of Transmission1.2-1.5MPaTorque Converter TypeSingle-stage,Duo-turbine,4-elementTorque Ratio4AxlesRigid Front Axle&Oscillating Rear AxleRear Axle Oscillation (°)±10°DifferentialConventionalMain ReducerSpiral Bevel,1-stage ReductionFinal ReducerPlanetary ReductionTire23.5-25 L-3 16PR TTTravel Speedskm/h1st2nd3rd4thForward11.536  Reverse16    BRAKE SYSTEMService BrakeSingle Circuit Caliper,Dry BrakeSetting Pressure0.70-0.78MPaParking BrakeAir Actuated Caliper BrakeEmergency BrakeAir Actuated Caliper Brake STEERING SYSTEMTypeHydraulic Load Sensing SystemPumpGear Pump,176L/min·2200rpmSystem Pressure15MPaCylinderTypeDouble ActingBore x Stroke2-100×324mmSteering Angle±35° HYDRAULIC SYSTEMTypeSingle-lever(Joystick) Control PumpGear Pump,220L/min·2200rpmControl Valve2 Spool (Bucket&Boom)System Pressure16MPaCylinderLift Cylinder2-180×721mmNo.-Bore x strokeTilt Cylinder1-200×563mmJoystick Control Pressure2.5MPaCycle TimeRaiseDumpLowerTotal(Sec)61411 SERVICE REFILL CAPACITYFuel Tank (L)285LHydraulic Tank (L)270/275(3rd Spool for Auxiliary Function)LCrankshaft (L)20LTransmission (L)46LFront Axle/Rear Axle (L)28L/28L
