• Model NO.：CDM833
• Type：Medium-sized Loader
• Bucket Capacity：1.7 Cbm
• Operating Weight：10300 Kg
• Engine：Weichai,Wp6g125e22
• Rated Power：92kw,2200rpm
• Rated Torque：500n.M,1400rpm
• Wheel Base：2850mm
• Load and Unload Method：Front Discharge
• Color：Yellow
• Warranty：1 Year
• Tire：23.5-25
• Transport Package：40 Hq
• Specification：ISO, CE
• Trademark：Lonking
• Origin：Shanghai, China
• HS Code：84295100
• Production Capacity：1000sets,Month

NO.

DESCRIPTIONUNITSTDHigh DumpAOverall Height - Bucket Raisedmm47375080BBucket Pin Height at Max. Liftmm37104064CDump Clearance at Max. Lift ( 45°) mm29043249DReach at Max. Lift and 45° Dumpmm10951002ERack Back Angle at Carry°46.346.6FRack Back Angle at Ground°4040.9GDigging Depthmm30-4030-40HRack Back Angle at Max. Lift°50.747IDump Angle at Max. Lift°46.645JCarry Heightmm400400KGround Clearancemm345345LCenter Line of Front Axle to Hitchmm14251425MWheel Basemm28502850NOverall Lengthmm72007450ODeparture Angle°2727PHeight to Top of Cabmm31803180QOverall Width over Bucketmm25002500RMin. Turning Radius over Bucket mm61906280SMin. Turning Radius over Tiresmm56755675TSteering Angle - Left/Right°3535UWidth at Tread Centermm18501850VOverall Width over Tiresmm23202320 OVERALL DATA                                                                  Bucket Capacity1.7m³1.7m³Rated Payload 3000kg 3000kgOperating Weight10300±300kg10500±300kgTraction Force97±3kN97±3kNBreakout Force105±3kN95±3kNL×W×H(mm)7200×2500×31807450×2500×3180 ENGINE&ELECTRICAL SYSTEMMaker/ModelWEICHAI/WP6G125E22Emission StandardEPA (Tier II)/National IIEngine Type4 Stroke,Turbocharged,Water-cooled,Direct Injection,Diesel EngineRated Power92kW(125hp)/2200rpmMaximum Torque500N·m/1400-1600rpmBore x Stroke (mm)105×130No. of Cylinders/Displacement6/6.75LCompression Ratio18Air CleanerThree Stage Air CleanerAlternator 55AmpBattery2-24V/105AhStarting Motor24V/6kWHeating Capacity (W)5000WCooling Capacity (W)4700W DRIVE TRAIN Transmission TypeCountershaft Powershift TransmissionShift TypeMechanical Powershift ControlPressure of Transmission1.1-1.5MPaTorque Converter TypeSingle-stage,Single-turbine,3-elementTorque Ratio3.2AxlesRigid Front Axle&Oscillating Rear AxleRear Axle Oscillation (°)±10°DifferentialConventionalMain ReducerSpiral Bevel,1-stage ReductionFinal ReducerPlanetary ReductionTire17.5-25 L-3 12PR TTTravel Speedskm/h1st2nd3rd4thForward7122436Reverse8.528   BRAKE SYSTEM Service BrakeSingle Circuit Caliper,Dry BrakeSetting Pressure0.70-0.78MPaParking BrakeFlexible Shaft Controlled Caliper Brake Emergency BrakeFlexible Shaft Controlled Caliper Brake  STEERING SYSTEM TypeHydraulic Load Sensing SystemPumpGear Pump,176L/min·2200rpmSystem Pressure14MPaCylinderTypeDouble ActingBore x Stroke2-80×315mmSteering Angle±35° HYDRAULIC SYSTEM TypeMechanical Shift Control PumpGear Pump,176L/min·2200rpmControl Valve2 Spool (Bucket&Boom)System Pressure16MPaCylinderLift Cylinder2-125×784mmNo.-Bore x strokeTilt Cylinder1-140×553mmJoystick Control Pressure--MPaCycle TimeRaiseDumpLowerTotal(Sec)5.51.33.710.5 SERVICE REFILL CAPACITYFuel Tank (L)200LHydraulic Tank (L)150/155(3rd Spool for Auxiliary Function)LCrankshaft (L)17LTransmission (L)36LFront Axle/Rear Axle (L)18.5L/18.5L
