• Model NO.：BJ956
• Type：Small Loader
• Rated Bucket Capacity：3m³
• Rated Revolution：2200rpm
• Torque Converter：50X53D
• Transport Package：Wooden Packaging
• Specification：7929x2845x3423mm
• Trademark：Beijun
• Origin：Shandong
• Production Capacity：1000 Set a Month

Basic Info.

Model NO. BJ956 Type Small Loader Rated Bucket Capacity 3m³ Rated Revolution 2200rpm Torque Converter 50X53D Transport Package Wooden Packaging Specification 7929x2845x3423mm Trademark Beijun Origin Shandong Production Capacity 1000 Set a Month

Product Description

Wheel loader price list 5 ton front end loader backhoe

BJ956 wheel Loader Feature:

1, Strong Power And High Torque Reserve Factor

2, Enhanced Heavy-Duty Drive Axle of Outstanding Performances

3, Best Driving and Riding Experience for the Operator

4, Human-Oriented Design Guarantee Safety and Reduce Fatigue

5, Long-Tested & Super-Strong Heavy-Duty Structural Parts

6, Frame Structure of Super-Strong Carrying Capacity

7, High Strength Wear-Resistant Bucket Design

Main Specifications:

Descriptions	Specifications
Rated Bucket Capacity	3m³
Rated Loading Capacity	5000kg
Overall Weight	16300kg
Maximum Breakout Force	155kN
Maximum Tractive Force	150kN
Maximum Dump Height	3400mm
Maximum Dump Reach	1083mm
Minimum Turning Radius	6201mm
Wheel Base	2920mm
Wheel Tread	2250mm
Overall Dimension(LxWxH)	7929x2845x3423mm
Engine
Engine Model	WEICHAI WD10G220E21
Engine Type	Vertical,in-line,Water cooled,4-Stroke diesel engine
Rated Power	162kW
Rated Revolution	2200rpm
Transmission System
Torque Converter	50X53D
Gearbox	50X53D
Gear Shift	2forward shift,1reverse shift
Maximum Speed	36km/h
Tyre	23.5-25
