• Model NO.：SG21A-3
• Min. Turning Radius：6600mm
• Operating Weight：11600kg
• Front Axle Load：3480kg
• Rear Axle Load：8120kg
• Max. Lifting Height：460mm
• Transport Package：Nude
• Specification：8225x3016x3515
• Trademark：Oriemac
• Origin：China
• Production Capacity：350units,Month

EngineEngine modelCummins 6CTAA8.3-C215Rated power/speed160   kW/2200 rpmEngine typeIn-line,   water-cooled, 4-cycle, direct injection, turbochargedNumber of cylinders6 (114 x   135 mm)Piston displacement8.3 LMaximum torque/speed980   N·m/1500 rpmMinimum fuel consumption 202 g/kW·htravel speedTransmission   and torque converter: Electronic controlled transmission with 6 forward gears   and 3 reverse gears.Gear1st2nd3rd4th5th6thForward0~5.4   km/h0~9.3   km/h0~12.2   km/h0~20.5km/h0~25.6   km/h0~39.7   km/hReverse0~5.4   km/h0~12.2   km/h0~25.4   km/h   TRAVELTire   Type17.5-25PR14Steering systemMax.   steering angle of front wheel ±45°Max. tilting angle of front wheel±17°Max. oscillating angle of front axle±15°Steering angle of frame±25°Max. oscillating angle of rear axle±15°Min. turning radius8200 mmOperation weightOperating   weight (standard configuration)17000 kgFront axle load5100 kgRear axle load11900 kgBladeBlade   length 3660/3965/4270   mmBlade height635 mmBlade rotational angle360°Cutting angle adjustment range44~91°Maximum cutting depth 500 mmCutting force per dozing 25.96/24.47/22.95   kN/mMaximum lift above ground 440 mmMaximum blade lateral extension (left/right) 1900/1950   mm
