• Model NO.：XE215C
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Maximum Digging Height：3475mm
• Maximum Digging Depth：2290mm
• Maximum Digging Radius：3900mm
• Walking Speed：3.9,1.9km,H
• Track Width：230mm
• Blade Width：1240mm
• Output Power：9.8,2300kw,Rpm
• Rotating Speed：9.5r,Min
• Gradeability：30
• Fuel Tank Capacity：18L
• Bucket Digging Force：16kn
• Length：9680mm
• Width：2980mm
• Height：3440mm
• Track Length：4250
• Transport Package：Nude
• Origin：Jiangsu, China
• Production Capacity：100units,Week

Operating weightKg1795Bucket capacity m³0.04EngineModel/D782-E3B-CBH-1Style       Direct injection/√Four strokes/√Water cooling/√Turbo-charging/×Air to air intercooler//No. of cylinders/3 Output powerkw/rpm9.8/2300torque/speedN.m44.5/1800 DisplacementL0.778Main performanceTravel speed(H/L)km/h4.3/2.2Rotating speedr/min9.5Gradeability°30°Ground pressurekPa28.5Bucket digging forcekN16Arm crowd forcekN10 Maximum tractionkN15.6Hydraulic systemMain pump//Rated flow of main pumpL/min56.8Pressure of prime valveMPa22Pressure of travel systemMPa22Pressure of swing systemMPa11Pressure of pilot systemMPa3.9Oil CapacityFuel tank capacity                                    L18Hydraulic tank capacity                              L17Engine oil capacity                                      L3.8
