• Model NO.：T165-3
• Condition：New
• Color：Yellow
• Operating Weight：17200 Kg
• Flywheel Power：121kw
• Ground Pressure：66.7
• Min. Ground Clearance：352.5
• Dozing Capacity：5
• Max. Digging Depth：420
• Operation Weight：17200
• Track Gauge：1880mm
• Gradient：30,25
• Blade Width：3297:(mm)
• Transport Package：Bulk
• Specification：SGS
• Trademark：KUDAT
• Origin：China
• Production Capacity：500PCS,Year

Basic Info.

Model NO. T165-3 Condition New Color Yellow Operating Weight 17200 Kg Flywheel Power 121kw Ground Pressure 66.7 Min. Ground Clearance 352.5 Dozing Capacity 5 Max. Digging Depth 420 Operation Weight 17200 Track Gauge 1880mm Gradient 30/25 Blade Width 3297:(mm) Transport Package Bulk Specification SGS Trademark KUDAT Origin China Production Capacity 500PCS/Year

Product Description

Semi-rigid suspended, mechanical transfer, hydraulic controlled track-type bulldozer. Oil booster control clutch, normally meshed helical gear drive, coupling sleeve shift and two lever operation, the transmission has five forward and four backward speeds. Single lever pilot hydraulic controls implement. Superior cabin is designed with streamline outlook and electric monitor. Been Popular among customers by its many merits such as productive efficiency, easy operated, low maintenance cost. T165-2 will be the ideal choice for transportation, desert working, oil field, electric power, mine project, etc. It is the updated product based on T165-1.

 1,General Specifications

Blade	Straight and tilting	Angular Blade
Ground pressure:(kpa)	66.7	67
Min. ground clearance:(mm)	352.5	352.5
Dozing capacity:(m3)	5	4.9
Max. digging depth:(mm)	420	377
Operation weight:(kg)	17200	17300
Track gauge:(mm)	1880	1880
Gradient:	30°/25°	30°/25°
Blade width:(mm)	3297	3762
Overall dimensions:(L×W×H)(mm)	5416×3297×3160	5716×3762×3160



2,Undercarriage System

Type:	Swing type of sprayed beam, suspended structure of equalizer bar.
Number of track rollers(each side)	6
Number of carrier rollers(each side)	2
Pitch (mm)	203
Width of shoe (mm)	500



3,Gear

	1st	2nd	3rd	4th	5th
Forward (Km/h)	0-2.50	0-3.30	0-5.68	0-7.53	0-10.64
Backward (Km/h)	0-3.53	0-4.61	0-7.94	0-10.53



4,Engine

Engine Name	Weichai WD10G178E25
Rated revolution:(rpm)	1850
Flywheel power (KW)	121
Max. torque:(N.m/rpm):	830/1000-1200
Rated fuel consumption:(g/kw.h)	≤215



5,Implement Hydraulic System

Max. system pressure (MPa):	12
System output(L/min)	185
Pump type:	Two groups Gears pump



6,Driving System

Main clutch:	Normally opened, wet type, hydraulic booster control.
Transmission:	Normally meshed helical gear drive, coupling sleeve shift and two lever operation, the transmission has five forward and four backward speeds.
Steering clutch:	Multiple-disc oil power metallurgy disc compressed by spring. hydraulic operated.
Braking clutch:	Brake is oil two direction floating band brake operated by mechanical foot pedal.
Final drive:	The final drive are double reduction with spur gear and   segment sprocket, which are sealed by duo-cone seal.
