XCMG Official Manufacturer G08K 8m3 Concrete Mixer Truck
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service:Overseas Service Center Available
- Warranty:1year
- Type:Concrete Mixing Truck
- Shotcrete Type:Semi-Dry
- Machining Process:Hydraulic
- Structure:Spiral Type
Base Info
- Model NO.:G08K
- Productivity:240m²,h
- Certification:ISO9001: 2000, 3c
- Condition:New
- Color:Yellow
- Weight:25000kg
- Transport Package:Comply with Export Packaging Requirements
- Specification:ISO
- Trademark:XCMG
- Origin:Xuzhou, Jiangsu, China
- HS Code:87059091
- Production Capacity:1000,Year
Description
Overview
Product Description
Product ParametersCatagoryItem Unit Parameter Overall Parameter Model G08K Curb weight kg 14000 Max.total weight kg 25000 Outline dimension (L×W×H) mm 8935×2500×3890 Chassis Chassis brand Sinotruk Chassis model ZZ1257N3641W Steering position LHD Driving type 6×4 Wheel base mm 3625+1350 Tire 10.00R20 Power take-off Flywheel Engine Model WD615.69 Max.power kW 247 Displacement L 9.726 Emission standard Euro II Drum system Geometric volume m³ 13.6 Agitating volume m³ 8 Max.diameter of drum mm 2280 Mixing drum length mm 4795 Slanting angle ° 15 Rotating speed r/min 0~14 Feeding speed m³/min ≥3 Discharge speed m³/min ≥2 Discharge residual rate % < 0.4 Slump scope mm 50~210 Product Show
Company Profile
FAQ
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
* On the basis of in-depth and integrative research on theindustry, the XCMG new generation truck mixers are system optimized by taking the integrated modularization design totruly realize the integrated innovation.
Product ParametersCatagory
Company Profile
FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
