14500kg Excavator Se150 From Shantui Manufacture with Factory Price
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type:Crawler Excavator
- Usage:GM Excavator
- Bucket:Backhoe
- Transmission:Hydraulic Transmission
- Drive Type:Electric Drive
- Bucket Capacity:0.45-0.7cbm
Base Info
- Model NO.:SE150
- Size:Medium-Sized
- Certification:CE, ISO9001: 2000
- Condition:New
- Ground Clearance of Counterweight (mm):915
- Minimum Ground Clearance (mm):425
- Tail Turning Radius (mm):2380
- Track Length (mm):3645
- Track Gauge (mm):2000
- Track Width (mm):2500
- Standard Track Shoe Width (mm):500
- Turntable Width (mm):2645
- Distance From Slewing Center to Tail (mm:2375
- Model:Qsf3.8t (China-III)
- Bucket Arm Digging Force (Kn):70
- Transport Package:Nude Package,RO-RO,Bulk Shipment,Suitable Containe
- Specification:4390*2860*2465mm
- Trademark:shantui
- Origin:China
- Production Capacity:300piece,Month
Description
Basic Info.
Model NO. SE150 Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Ground Clearance of Counterweight (mm) 915 Minimum Ground Clearance (mm) 425 Tail Turning Radius (mm) 2380 Track Length (mm) 3645 Track Gauge (mm) 2000 Track Width (mm) 2500 Standard Track Shoe Width (mm) 500 Turntable Width (mm) 2645 Distance From Slewing Center to Tail (mm 2375 Model Qsf3.8t (China-III) Bucket Arm Digging Force (Kn) 70 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 4390*2860*2465mm Trademark shantui Origin China Production Capacity 300piece/MonthProduct Description
14500Kg Excavator SE150 From Shantui Manufacture With Factory PriceContact Ash for more information________________________________________________________________________________________________________________________
CHARACTERISTICHigh-end system configuration
Cummins high pressure common rail electronic injection engine features high power reserve and strong power.
The full set of Kawasaki negative-flow system features high stability and reliability and is the golden configuration among the products of same tonnage.
This machine features high system pressure, high flow, and fast motion response, with maximum digging force up to 105KN.
The comprehensively optimized working device and the cast shaft seats for boom and arm feature high strength, good wear resistance, and long life.
The two-sided support track rollers in place of carrier rollers, two one-sided track guides, and the reinforced X-frame are installed to adapt to severe working conditions.
The optional 0.65m3 rock bucket is designed specially for rock working condition.
Enhanced working deviceThe structures of critical portions are comprehensively optimized and the load-carrying positions are reinforced to resist against severe working conditions.
The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
Based on the digging path of the bucket, the bucket structure is optimized to reduce the digging resistance and improve the digging efficiency.
The H-shaped track frame features strong carrying capacity and reasonable machine load distribution. The track frame is equipped with standard boarding footplate to mitigate the user's labor strength and improve the user satisfaction.
Drive sprockets, idlers, track rollers, carrier rollers, and tracksDecades of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and world's leading technologies.
The world's sophisticated forging and heat treatment processes guarantee stable and reliable quality.
Intelligent electronic control and optimal power controlThe intelligent control system realizes the optimal match between power system and hydraulic system to improve the working efficiency. The automatic idling function is provided to lower the fuel consumption and reduce the operating cost.
The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.
Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.
Spacious and comfortable operating environmentThe colors of the all-injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.
The control devices are reasonably arranged to realize large space, broad vision, and convenient and comfortable operations.
The high-power A/C is installed and the adjustable wrist rest and the air cushioned seat are provided to help your all-day comfortable operations.
Quick and convenient maintenancesThe fully openable engine hood is installed with locating mechanism to realize handy and safe opening, large engine compartment space, and easy maintenances.
The electric parts are centrally arranged to ease the checking and maintenances.
The filling of washing fluid, the replacement of air filter element, and the power master switch are easily accessible.
Optional equipment of machineRefueling pump
Cab warning lamp
Cab ceiling lamp
Cab overhead protective net
Cab front upper protective net
Cab front lower protective net
Rubber track
Narrow bucket
Optional attachmentsBreaking hammer, ripper, timber grab, stone grab, quick change coupling, hydraulic tamper, quick change coupling, and breaking hammer pipeline.
PARAMETERComparative item | SE150 (Standard version) |
Overall dimensions | |
Overall length (mm) | 7860 |
Ground length (During transport) (mm) | 4390 |
Overall height (To the top of boom) (mm) | 2860 |
Overall width (mm) | 2645 |
Overall height (To top of cab) (mm) | 2855 |
Ground clearance of counterweight (mm) | 915 |
Minimum ground clearance (mm) | 425 |
Tail turning radius (mm) | 2380 |
Track length (mm) | 3645 |
Track gauge (mm) | 2000 |
Track width (mm) | 2500 |
Standard track shoe width (mm) | 500 |
Turntable width (mm) | 2645 |
Distance from slewing center to tail (mm) | 2375 |
Working range | |
Maximum digging height (mm) | 8670 |
Maximum dumping height (mm) | 6210 |
Maximum digging depth (mm) | 5490 |
Maximum vertical digging depth (mm) | 4625 |
Maximum digging distance (mm) | 8325 |
Maximum digging distance at ground level (mm) | 8195 |
Working device minimum turning radius (mm) | 2395 |
Maximum lifting height of bulldozer blade (mm) | - |
Maximum digging depth of bulldozer blade (mm) | - |
Engine | |
Model | QSF3.8T (China-III) |
Type | 4-cylinder, high pressure common rail, and water-cooled and turbocharged |
Displacement (L) | 3.76 |
Rated power (kW/rpm) | 86/2200 |
Hydraulic system | |
Type of hydraulic pump | Variable displacement duplex plunger pump |
Rated working flow (L/min) | 2x130 |
Bucket | |
Bucket capacity (m³) | 0.65 |
Swing system | |
Maximum swing speed (r/min) | 11.3 |
Brake type | Mechanically applied and pressure released |
Digging force | |
Bucket arm digging force (KN) | 70 |
Bucket digging force (KN) | 97 |
Operating weight and ground pressure | |
Operating weight (kg) | 14500 |
Ground pressure (kPa) | 43.8 |
Traveling system | |
Traveling motor | Axial variable displacement plunger motor |
Traveling speed (km/h) | 3.25/5.2 |
Traction force (KN) | 118 |
Gradeability | 70%(35°) |
Tank capacity | |
Fuel tank capacity (L) | 220 |
Cooling system (L) | 20 |
Engine oil capacity (L) | 12 |
Hydraulic oil tank/system capacity (L) | 177/205 |
