• Model NO.：SE60
• Certification：CE, ISO9001: 2000
• Condition：New
• Overall Height (to Top of Cab) (mm)：2585
• Ground Clearance of Counterweight (mm)：710
• Minimum Ground Clearance (mm)：300
• Tail Turning Radius (mm)：1655
• Track Length (mm)：2560
• Track Gauge (mm)：1480
• Track Width (mm)：1880
• Standard Track Shoe Width (mm)：400
• Turntable Width (mm)：1780
• Distance From Slewing Center to Tail (mm：1655
• Maximum Digging Height (mm)：5785mm
• Maximum Dumping Height (mm)：4075mm
• Maximum Digging Depth (mm)：3850mm
• Maximum Vertical Digging Depth (mm)：3000
• Maximum Digging Distance (mm)：6200
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Containe
• Specification：3330*2060*1880mm
• Trademark：shantui
• Origin：China
• Production Capacity：300piece,Month

Basic Info.

Model NO. SE60 Certification CE, ISO9001: 2000 Condition New Overall Height (to Top of Cab) (mm) 2585 Ground Clearance of Counterweight (mm) 710 Minimum Ground Clearance (mm) 300 Tail Turning Radius (mm) 1655 Track Length (mm) 2560 Track Gauge (mm) 1480 Track Width (mm) 1880 Standard Track Shoe Width (mm) 400 Turntable Width (mm) 1780 Distance From Slewing Center to Tail (mm 1655 Maximum Digging Height (mm) 5785mm Maximum Dumping Height (mm) 4075mm Maximum Digging Depth (mm) 3850mm Maximum Vertical Digging Depth (mm) 3000 Maximum Digging Distance (mm) 6200 Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Containe Specification 3330*2060*1880mm Trademark shantui Origin China Production Capacity 300piece/Month

Product Description

Shantui Mini Excavator SE60 With 0.22Cbm Bucket Capacity In Stock
Contact  Ash for more information



CHARACTERISTIC:High-end system configuration

The high-performance turbocharged engine with mechanical pump features high power, low fuel consumption, and powerful fuel adaptability. The all-new load-sensing hydraulic system and the over-class high-displacement constant-power pump matches with low pressure loss main valve and large bore pipeline to realize smooth operations and fast response and improve the efficiency by >8.5%.

Firm and durable structural parts

The upper frame adopts the modal analysis technology to realize high firmness and durability while effectively reducing the vibration and noise of machine.

The design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.

The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.

Comfortable and convenient operating environment

The colors of the all-injection-molded interior trim parts are effectively matched as per ergonomics to mitigate the operator's visual fatigue.

The cab in high-strength irregular-shaped tubular framework structure features broad forward and backward visions and high working safety and is installed with fire extinguisher, escape hammer, and seat belt.

The high-power A/C system outputs pleasant airflow in three-dimensional manner. The air cushioned seat is adjustable by two-stage slideways. The excellent shock-absorbing and noise-reduction performance can realize a perfect driving/riding comfort.

Highly reliable traveling device

With 30 years of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and with industry's high-end technologies, it's the first choice for excavators.

The mature and high-quality forging and heat treatment processes guarantee stable and reliable quality.

The track rollers of same specification with 7T class are installed to realize high firmness and durability and long life.

Intelligent electronic control and optimal power control

The intelligent control system realizes high match between power system and hydraulic system to improve the working efficiency and reduce the fuel consumption.

The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.

Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.

Convenient maintenances

The washer is installed on the left side of engine compartment to ease the checking and refilling.

The fully openable engine hood is installed with locating mechanism to realize handy and safe opening, large engine compartment space, and easy maintenances.

The electric parts are centrally arranged on the right front tool compartment to ease the checking and maintenance.

The filling of coolant and the replacement of air filter are easily accessible.

Optional equipment of machine

Refueling pump

Cab warning lamp

Cab ceiling lamp

Cab overhead protective net

Cab front upper protective net

Cab front lower protective net

Rubber track

Narrow bucket

Wide bucket

Optional attachments

Crusher

Ripper

Timber grab

Hydraulic tamper

Stone grab

Breaking hammer pipeline

PARAMETER

Comparative item	SE60(Homemade configuration version)
Overall dimensions
Overall length (mm)	5855
Ground length (During transport) (mm)	3330
Overall height (To the top of boom) (mm)	2060
Overall width (mm)	1880
Overall height (To top of cab) (mm)	2585
Ground clearance of counterweight (mm)	710
Minimum ground clearance (mm)	300
Tail turning radius (mm)	1655
Track length (mm)	2560
Track gauge (mm)	1480
Track width (mm)	1880
Standard track shoe width (mm)	400
Turntable width (mm)	1780
Distance from slewing center to tail (mm)	1655
Working range
Maximum digging height (mm)	5785
Maximum dumping height (mm)	4075
Maximum digging depth (mm)	3850
Maximum vertical digging depth (mm)	3000
Maximum digging distance (mm)	6200
Maximum digging distance at ground level (mm)	6060
Working device minimum turning radius (mm)	2395
Maximum lifting height of bulldozer blade (mm)	385
Maximum digging depth of bulldozer blade (mm)	465
Engine
Model	Kubota V2607T(China-III)
Type	4-cylinder inline and turbocharged
Displacement (L)	2.615
Rated power (kW/rpm)	36/2000
Hydraulic system
Type of hydraulic pump	Variable displacement plunger pump
Rated working flow (L/min)	152
Bucket
Bucket capacity (m³)	0.18~0.22(0.22)
Swing system
Maximum swing speed (r/min)	11
Brake type	Mechanically applied and pressure released
Digging force
Bucket arm digging force (KN)	29
Bucket digging force (KN)	48
Operating weight and ground pressure
Operating weight (kg)	5960
Ground pressure (kPa)	33
Traveling system
Traveling motor	Axial variable displacement plunger motor
Traveling speed (km/h)	2.7/4.6
Traction force (KN)	50
Gradeability	70%(35°)
Tank capacity
Fuel tank capacity (L)	95
Cooling system (L)	8.5
Engine oil capacity (L)	9
Hydraulic oil tank/system capacity (L)	74/110
