• Model NO.：DH10-C2
• Engine Power：>515kw
• Certification：CE
• Condition：New
• Color：Yellow
• Engine Model：Qsf3.8
• Transport Package：Cartons
• Specification：4442*2860*2885mm
• Trademark：shantui
• Origin：China
• HS Code：8429521200
• Production Capacity：500000

Basic Info.

Model NO. DH10-C2 Engine Power >515kw Certification CE Condition New Color Yellow Engine Model Qsf3.8 Transport Package Cartons Specification 4442*2860*2885mm Trademark shantui Origin China HS Code 8429521200 Production Capacity 500000

Product Description

Mini Size Bulldozer Shantui Brand Dh10-C2 with Competitive Price



Product Description




The long life design ensures high firmness and durability.

* Boat type frame of high carrying capacity: The boat type frame structure and the cast and welded rear axle feature high carrying capacity, high resistance against impact and bending moment, less welding, high strength, high reliability, and safer internal parts.

* New track roller frame and final drive of higher durability: The planetary final drive features small volume, high carrying capacity, and high plane installation strength. The integral track roller frame features high durability, high resistance against mud accumulation and traveling wear, and long life.

* Double drive shock-absorbing structure of higher durability: The newly added shock absorber assembly absorbs the impact load to protect the drive system. The drive assembly installation adopts semi-suspension elastic shock absorber to isolate the transmission of impact and double the comprehensive life.

* Wearing parts of higher wear resistance: The wheel train are made of high-strength wear-resistant materials, with the overall quenched wearing layer thickness 2 times of that of domestic competing products and the cutting edges and end bits thicker by >20% than those of domestic competing products.



Parameter name	DH10-C2 XL (Extended version)	DH10-C2 LGP(Super-wetland version)
Performance parameters
Operating weight (Kg)	9680kg/21341lb (With traction frame)	10140kg/22355lb (With traction frame)
Ground pressure (kPa)	44.4	34
Engine
Engine model	QSF3.8	QSF3.8
Rated power/rated speed (kW/rpm)	86/2200	86/2200
Overall dimensions
Overall dimensions of machine (mm)	4442*2860*2885	4442*3200*2885
Driving performance
Forward speed (km/h)	0~9km/h(5.6mph)	0~9km/h(5.6mph)
Reversing speed (km/h)	0~9km/h(5.6mph)	0~9km/h(5.6mph)
Chassis System
Center distance of track (mm)	1650	1790
Width of track shoes (mm)	460	630
Ground length(mm)	2320	2320
Tank capacity
Fuel tank (L)	197	197
Working device
Blade type	PAT	PAT
Digging depth (mm)	450	450
Ripper type	Three-tooth ripper	Three-tooth ripper
Ripping depth (mm)	340	340
