Cheap Price Shantui 36kw Double Drum Road Roller Hot Sale (SRD04)
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Road Roller
- Working Method：Vibration
- Axle：Biaxial Dual-Drum
- Grinding Wheel Type：Tire Grind
Base Info
- Model NO.：SRD04
- Compaction Depth：40cm
- Engine Type：Diesel Engine
- Travel Speed：0-6km,H
- Centrifugal Force：82,40
- Certification：CE, ISO 9001:2000
- Condition：New
- Operating Weight (Kg)：4200 Road Roller
- Exciting Force (Kn)：40
- Vibration Frequency (Hz)：60
- Ground Pressure (Kpa)：200-460
- Gradeability (%)：40
- Engine Model：Yamar 488
- Rated Power/Rated Speed (Kw/Rpm)：35kw,3000rpm
- Wheelbase (mm)：1950
- Fuel Tank (L)：75
- Compacting Width(mm)：1400
- Transport Package：Container,RO-RO
- Specification：3000*1670*2200 mm
- Trademark：SHANTUI
- Origin：China
- HS Code：8429401900
- Production Capacity：100units,Month
Description
Basic Info.
Model NO. SRD04 Compaction Depth 40cm Engine Type Diesel Engine Travel Speed 0-6km/H Centrifugal Force 82/40 Certification CE, ISO 9001:2000 Condition New Operating Weight (Kg) 4200 Road Roller Exciting Force (Kn) 40 Vibration Frequency (Hz) 60 Ground Pressure (Kpa) 200-460 Gradeability (%) 40 Engine Model Yamar 488 Rated Power/Rated Speed (Kw/Rpm) 35kw/3000rpm Wheelbase (mm) 1950 Fuel Tank (L) 75 Compacting Width(mm) 1400 Transport Package Container/RO-RO Specification 3000*1670*2200 mm Trademark SHANTUI Origin China HS Code 8429401900 Production Capacity 100units/MonthProduct Description
Cheap Price SHANTUI 36kW Double Drum Road Roller HOT Sale (SRD04)
Product discription
Hydraulic system
It's applied with double drive traveling system composed of imported plunger pumps and plunger motors and is equipped with automatic parking brake mechanism.
The vibrating drum is driven by imported hydraulic parts, with free changeover between single and double vibrating modes.
The hydraulic articulated steering system features flexible motions and effectively adapts to diversified working conditions.
PARAMETER
| Parameter name | SRD04 |
| Performance parameters | |
| Operating weight (Kg) | 4200 |
| Exciting force (KN) | 40 |
| Vibration frequency (Hz) | 60 |
| Nominal amplitude (mm) | 0.5 |
| Ground pressure (KPa) | - |
| Gradeability (%) | 40 |
| Engine | |
| Engine model | Yamar 488 |
| Rated power/rated speed (kW/rpm) | 35kw/3000rpm |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 3000*1670*2200 |
| Driving performance | |
| Forward speed (km/h) | 0-12 |
| Reversing speed (km/h) | 0-12 |
| Chassis System | |
| Wheelbase (mm) | 1950 |
| Tank capacity | |
| Fuel tank (L) | 70 |
| Working device | |
| Compacting width(mm) | 1400 |
