• Model NO.：TL2000
• Load and Unload Mode：Front Discharge
• Walking Mode：Wheeled
• Type：Small Loader
• Color：Customized
• Engine：Yunnei
• Power：65 Kw
• Bucket Capacity：1 Cbm
• Max. Lifting Height：5000mm
• Tire：16,70-20
• Name：Manufacturer Hydraulic Small Wheel Loader Articula
• Operating Weight：5500kg
• Transport Package：Container
• Specification：6600x2750x2050mm
• Trademark：HERACLES
• Origin：China
• HS Code：8429510000
• Production Capacity：1000 Pieces,Year

Main technical specification:
1.0 Engine Details
(1) Model: YUNNEI Turbocharged Engine
(2) Engine Type:In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 65KW
(4) Rated Speed: 2400 r/p.min (rpm)
2.0 Transmission System
Hydraulic converter + gearbox+drive shaft + hub reduction axles
3.0 Bucket
(1) Bucket Capacity: 1m³
(2) Bucket width: 1900mm
(3) Bucket type:Heavy-duty bolt on teeth
(5) Rated Load: 2000kg including attachment or bucket
4.0 Overall Dimensions
(1) Overall Length: 6600mm
(2) Overall Height:2750mm
(3) Overall Width: 2050mm
(4) Max. lifting Height:5000mm
(5) Lifting to bucket hinge pin Height:4500mm
(6) Bucket Unloading Height:3950mm
(7) Unloading Distance:  1950mm(Arm extended)
                                            1150mm(Arms recovered)
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4600mm(The right front wheel)
   Min Turning Radius: 2300mm(The left rear wheel)
(3) Driving System: Hydraulic converter, four wheel drive
(4) Hydraulic joystick control.
6.0 Brake System
(1) Service Brake:Safer air assist disc brake braking system
(2) Parking Brake:Hand operated(Disc brakes)
7.0 Tire

1. FAQ

   Q1:Are you original manufacture?
   Yes, we are an official leading manufacture in construction machinery in China.

   Q2:What's your payment term?
   Normally we accept payment term T/T

   Q3: What about the Minimum Order Quantity?
   Our MOQ is 1 unit.

   Q4. Do you offer OEM,ODM service?
   Yes,OEM,ODM service available. Welcome to contact anytime.

   Q5: What about the warranty time?
   One year warranty.
