• Model NO.：FL936H
• Type：Medium-sized Loader
• Operating Mass(Kg)：10250
• Bucket Capacity：2.0
• Rated Load(Kg)：3000
• Traction(Kn)：101
• Digging Force(Kn)：98
• Unloading Height(mm)：2935
• Unloading Distance(mm)：1100
• Wheelbase(mm)：2880
• Model：Weichai Wp6g125e22
• Rated Power(Kw)：92
• Transport Package：Nude
• Specification：FL936H
• Trademark：LOVOL
• Production Capacity：1000 Units Per Month

Main paramaterOperating mass(kg)10250Bucket capacity2.0Rated load(kg)3000Traction(kN)101Digging force(kN)98Gradeability30Unloading height(mm)2935Unloading distance(mm)1100Min. ground diatance(mm)340Wheel tread(mm)1850Wheelbase(mm)2880Bucket outer turning radius(mm)5990Outline distance(mm)7170*2420*3200EngineModelWeichai WP6G125E22Max. torque(N·m)500Rated power(kW)92Rated rotational speed(rpm)2200Running systemGearbox shiftFront:4 gears Rear:2 gearsMax. speed39Type17.5-25Ply rating12Steering angle38OtherOperating modelMechanically controlSum of three items(s)9.2Fuel tank(L)170Hydraulic oil tank(L)120

Product specifications

Supporting EquipmentStandard bucket, stone bucket, quickchange bucket, quick change bottom fork, wooden fork, grass fork, fork; cold start device can be optionally equipped to deal with the cold circumstance
